GEM for SIPLACE V5.01 ©Siemens AG, all rights r eserved page 201 of 252 CEID Nam e Descript ion 311219 FM_AX_ANFRAGE_VERSION Axis er ror: com m unication during version interr ogation* 1 311220 FM_AX_VERSION_AX H Axis er…
GEM for SIPLACE V5.01
Page 200 of 252 ©Siemens AG, all rights reserved
CEID Name Description
311188 FM_D_IC_DA_TEST IC/D axis: testing DA outputs faulty* 1
311189 FM_X_ZAEHLSPUREN_TEST X axis: testing counting tracks faulty* 1
311190 FM_Y_ZAEHLSPUREN_TEST Y axis: testing counting tracks faulty* 1
311191 FM_S_ZAEHLSPUREN_TEST S axis: testing counting tracks faulty* 1
311192 FM_Z_SP_ZAEHLSPUREN_TES
T
SP/Z axis: testing counting tracks
faulty*
1
311193 FM_D_ZAEHLSPUREN_TEST SP/D axis: testing counting tracks
faulty*
1
311194 FM_Z_IC_ZAEHLSPUREN_TES
T
IC/Z axis: testing counting tracks
faulty*
1
311195 FM_D_IC_ZAEHLSPUREN_TES
T
IC/D axis: testing counting tracks
faulty*
1
311196 FM_X_DA_ABGLEICH_TEST X axis: DA calibration faulty* 1
311197 FM_Y_DA_ABGLEICH_TEST Y axis: DA calibration faulty* 1
311198 FM_S_DA_ABGLEICH_TEST S axis: DA calibration faulty* 1
311199 FM_Z_SP_DA_ABGLEICH_TES
T
SP/Z axis: DA calibration faulty* 1
311200 FM_D_DA_ABGLEICH_TEST SP/D axis: DA calibration faulty* 1
311201 FM_D_IC_DA_ABGLEICH_TEST IC/D axis: DA calibration faulty* 1
311202 FM_Z_IC_DA_ABGLEICH_TEST IC/Z axis: DA calibration faulty* 1
311203 FM_X_UNDEFINIERT X axis: error number undefined* 1
311204 FM_Y_UNDEFINIERT Y axis: error number undefined* 1
311205 FM_S_UNDEFINIERT S axis: error number undefined* 1
311206 FM_Z_SP_UNDEFINIERT SP/Z axis: error number undefined* 1
311207 FM_D_UNDEFINIERT SP/D axis: error number undefined* 1
311208 FM_Z_IC_UNDEFINIERT IC/Z axis: error number undefined* 1
311209 FM_D_IC_UNDEFINIERT IC/D axis: error number undefined* 1
311210 FM_AX_STD_DATEN Axis error: standard data not read* 1
311211 FM_AX_MA_DATEN Axis error: MA data not read* 1
311212 FM_AX_STD_FILE Axis error: Standard data file not
found*
1
311213 FM_AX_MA_FILE Axis error: standard data file not
found*
1
311214 FM_AX_KMD_ENDE Axis error: no end flag before new
command*
1
311215 FM_AX_KMD_DAIN Axis error: no DAIN flag before new
command*
1
311216 FM_AX_KMD_ENDE_SET Axis error: Command end, but bit set* 1
311217 FM_AX_KMD_DAIN_SET Axis error: Command DAIN, but bit
set*
1
311218 FM_AX_ANFRAGE_ID Axis error: no ID for MBX inquiry* 1
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 201 of 252
CEID Name Description
311219 FM_AX_ANFRAGE_VERSION Axis error: communication during
version interrogation*
1
311220 FM_AX_VERSION_AXH Axis error: AX_Version user* 1
311221 FM_AX_ANFRAGE_ADR Axis error: Communication during axis
interrogation*
1
311222 FM_AX_ANFRAGE_FUNC Axis error: Communication during
function address interrogation*
1
311223 FM_D_IC_PROG_FEHLER Programmed position of D-axis
outside of travel range*
1
311224 FM_Z_IC_PROG_FEHLER Programmed position of Z-axis
outside of travel range*
1
311225 FM_Z_IC_SERVO_FREI IC/Z axis: disabled* 1
311226 FM_D_IC_SERVO_FREI IC/D axis: disabled* 1
311227 FM_X_INIT_SCHRITTM X axis: Step motor initialisation
incorrect*
1
311228 FM_Y_INIT_SCHRITTM Y axis: Step motor initialisation
incorrect*
1
311229 FM_S_INIT_SCHRITTM S axis: Step motor initialisation
incorrect*
1
311230 FM_Z_SP_INIT_SCHRITTM RV/Z axis: Step motor initialisation
incorrect*
1
311231 FM_D_INIT_SCHRITTM RV/D axis: Step motor initialisation
incorrect*
1
311232 FM_Z_IC_INIT_SCHRITTM IC/Z axis: Step motor initialisation
incorrect*
1
311233 FM_D_IC_INIT_SCHRITTM IC/D axis: Step motor initialisation
incorrect*
1
311234 FM_X_TACHOBRUCH X axis: Tachometer defective* 1
311235 FM_Y_TACHOBRUCH Y axis: Tachometer defective* 1
311236 FM_S_TACHOBRUCH S axis: Tachometer defective* 1
311237 FM_Z_SP_TACHOBRUCH RV/Z axis: Tachometer defective* 1
311238 FM_D_TACHOBRUCH RV/D axis: Tachometer defective* 1
311239 FM_Z_IC_TACHOBRUCH IC/Z axis: Tachometer defective* 1
311240 FM_D_IC_TACHOBRUCH IC/D axis: Tachometer defective* 1
311241 FM_X_SERVO_FREI_VC X axis: Faulty servo activation
(counting track error) *
1
311242 FM_Y_SERVO_FREI_VC Y axis: Faulty servo activation
(counting track error) *
1
311243 FM_S_SERVO_FREI_VC S axis: Faulty servo activation
(counting track error) *
1
311244 FM_Z_SP_SERVO_FREI_VC RV/Z axis: Faulty servo activation
(counting track error) *
1
311245 FM_D_SERVO_FREI_VC RV/D axis: Faulty servo activation 1
GEM for SIPLACE V5.01
Page 202 of 252 ©Siemens AG, all rights reserved
CEID Name Description
(counting track error) *
311246 FM_Z_IC_SERVO_FREI_VC IC/Z axis: Faulty servo activation
(counting track error) *
1
311247 FM_D_IC_SERVO_FREI_VC IC/D axis: Faulty servo activation
(counting track error) *
1
311248 FM_X_NOREF_I_EFF X-axis: No longer referenced due to I-
eff. error*
1
311249 FM_Y_NOREF_I_EFF Y-axis: No longer referenced due to I-
eff. error*
1
311250 FM_S_NOREF_I_EFF S-axis: No longer referenced due to I-
eff. error*
1
311251 FM_Z_SP_NOREF_I_EFF RV/Z-axis: No longer referenced due
to I-eff. error*
1
311252 FM_D_NOREF_I_EFF RV/D-axis: No longer referenced due
to I-eff. error*
1
311253 FM_Z_IC_NOREF_I_EFF IC/Z-axis: No longer referenced due to
I-eff. error*
1
311254 FM_D_IC_NOREF_I_EFF IC/D-axis: No longer referenced due
to I-eff. error*
1
311255 FM_X_ZAEHLF_KOMMUTF X-axis: counting error (machine stop)* 1
311256 FM_Y_ZAEHLF_KOMMUTF Y-axis: counting error (machine stop)* 1
311257 FM_S_ZAEHLF_KOMMUTF S-axis: counting error (machine stop)* 1
311258 FM_Z_SP_ZAEHLF_KOMMUTF RV/Z-axis: counting error (machine
stop) *
1
311259 FM_D_ZAEHLF_KOMMUTF RV/D-axis: counting error (machine
stop) *
1
311260 FM_Z_IC_ZAEHLF_KOMMUTF IC/Z-axis: counting error (machine
stop) *
1
311261 FM_D_IC_ZAEHLF_KOMMUTF IC/D-axis: counting error (machine
stop) *
1
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these axis
collection events.
)LGXFLDOV
CEID Name Description
410001 MaFiducal machine fiducial recognized 1
410002 PCBfiducal PCB <FIDUCIALDATA> recognized 13
410003 FeederFiducial Feeder / WPC - <FIDUCIALDATA>
recognized
13
410004 FiducialTaught <TAUGHTFIDUCIAL> was taught at
the station. The Event occurs when
25
