GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 201 of 252
CEID Name Description
311219 FM_AX_ANFRAGE_VERSION Axis error: communication during
version interrogation*
1
311220 FM_AX_VERSION_AXH Axis error: AX_Version user* 1
311221 FM_AX_ANFRAGE_ADR Axis error: Communication during axis
interrogation*
1
311222 FM_AX_ANFRAGE_FUNC Axis error: Communication during
function address interrogation*
1
311223 FM_D_IC_PROG_FEHLER Programmed position of D-axis
outside of travel range*
1
311224 FM_Z_IC_PROG_FEHLER Programmed position of Z-axis
outside of travel range*
1
311225 FM_Z_IC_SERVO_FREI IC/Z axis: disabled* 1
311226 FM_D_IC_SERVO_FREI IC/D axis: disabled* 1
311227 FM_X_INIT_SCHRITTM X axis: Step motor initialisation
incorrect*
1
311228 FM_Y_INIT_SCHRITTM Y axis: Step motor initialisation
incorrect*
1
311229 FM_S_INIT_SCHRITTM S axis: Step motor initialisation
incorrect*
1
311230 FM_Z_SP_INIT_SCHRITTM RV/Z axis: Step motor initialisation
incorrect*
1
311231 FM_D_INIT_SCHRITTM RV/D axis: Step motor initialisation
incorrect*
1
311232 FM_Z_IC_INIT_SCHRITTM IC/Z axis: Step motor initialisation
incorrect*
1
311233 FM_D_IC_INIT_SCHRITTM IC/D axis: Step motor initialisation
incorrect*
1
311234 FM_X_TACHOBRUCH X axis: Tachometer defective* 1
311235 FM_Y_TACHOBRUCH Y axis: Tachometer defective* 1
311236 FM_S_TACHOBRUCH S axis: Tachometer defective* 1
311237 FM_Z_SP_TACHOBRUCH RV/Z axis: Tachometer defective* 1
311238 FM_D_TACHOBRUCH RV/D axis: Tachometer defective* 1
311239 FM_Z_IC_TACHOBRUCH IC/Z axis: Tachometer defective* 1
311240 FM_D_IC_TACHOBRUCH IC/D axis: Tachometer defective* 1
311241 FM_X_SERVO_FREI_VC X axis: Faulty servo activation
(counting track error) *
1
311242 FM_Y_SERVO_FREI_VC Y axis: Faulty servo activation
(counting track error) *
1
311243 FM_S_SERVO_FREI_VC S axis: Faulty servo activation
(counting track error) *
1
311244 FM_Z_SP_SERVO_FREI_VC RV/Z axis: Faulty servo activation
(counting track error) *
1
311245 FM_D_SERVO_FREI_VC RV/D axis: Faulty servo activation 1
GEM for SIPLACE V5.01
Page 202 of 252 ©Siemens AG, all rights reserved
CEID Name Description
(counting track error) *
311246 FM_Z_IC_SERVO_FREI_VC IC/Z axis: Faulty servo activation
(counting track error) *
1
311247 FM_D_IC_SERVO_FREI_VC IC/D axis: Faulty servo activation
(counting track error) *
1
311248 FM_X_NOREF_I_EFF X-axis: No longer referenced due to I-
eff. error*
1
311249 FM_Y_NOREF_I_EFF Y-axis: No longer referenced due to I-
eff. error*
1
311250 FM_S_NOREF_I_EFF S-axis: No longer referenced due to I-
eff. error*
1
311251 FM_Z_SP_NOREF_I_EFF RV/Z-axis: No longer referenced due
to I-eff. error*
1
311252 FM_D_NOREF_I_EFF RV/D-axis: No longer referenced due
to I-eff. error*
1
311253 FM_Z_IC_NOREF_I_EFF IC/Z-axis: No longer referenced due to
I-eff. error*
1
311254 FM_D_IC_NOREF_I_EFF IC/D-axis: No longer referenced due
to I-eff. error*
1
311255 FM_X_ZAEHLF_KOMMUTF X-axis: counting error (machine stop)* 1
311256 FM_Y_ZAEHLF_KOMMUTF Y-axis: counting error (machine stop)* 1
311257 FM_S_ZAEHLF_KOMMUTF S-axis: counting error (machine stop)* 1
311258 FM_Z_SP_ZAEHLF_KOMMUTF RV/Z-axis: counting error (machine
stop) *
1
311259 FM_D_ZAEHLF_KOMMUTF RV/D-axis: counting error (machine
stop) *
1
311260 FM_Z_IC_ZAEHLF_KOMMUTF IC/Z-axis: counting error (machine
stop) *
1
311261 FM_D_IC_ZAEHLF_KOMMUTF IC/D-axis: counting error (machine
stop) *
1
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these axis
collection events.
)LGXFLDOV
CEID Name Description
410001 MaFiducal machine fiducial recognized 1
410002 PCBfiducal PCB <FIDUCIALDATA> recognized 13
410003 FeederFiducial Feeder / WPC - <FIDUCIALDATA>
recognized
13
410004 FiducialTaught <TAUGHTFIDUCIAL> was taught at
the station. The Event occurs when
25
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 203 of 252
CEID Name Description
the operator saves the modified data.
411001 FM_LAGE_DETERMINANTE 94 DETERMINANT not correct during
position recognition*
1
411002 FM_LAGE_MARKE_FEHLT 95 Fiducial missing in position
recognition*
1
411003 FM_LAGE_KORR_ANFAHREN 96 CORR_MOVE not correct during
position recognition*
1
411004 FM_LAGE_MARKEN_ART Fiducial type (fid/ink spot) not correct* 1
411005 FM_FLE_N_MOEGL Limited conveyor position recognition* 1
411006 FM_FLE_N_MOEGL_SPUR Conveyor position recognition not
possible*
1
411007 FM_FOERD_MARKE_FEHLT feeder fiducial not found* 1
411008 FM_WPW_MARKE_FEHLT wafffle pack changer fiducial not
found*
1
411009 FM_PORTALUNRUHE_X X-axis moving during measurement* 1
411010 FM_PRTALUNRUHE_Y Y-axis moving during measurement* 1
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these fiducials
collection events.
9LVLRQ
CEID Name Description
510001 PackFormModified <MODIFIEDPACKAGEFORM> was
modified at the station. The Event
occurs when the operator saves the
modified data.*
26
511001 FM_INIT_HS3L Error during MVS-initialization via
HS3L*
1
511002 FM_ANZ_FOV Component too large for opt. multiple
measurement*
1
511003 FM_MVS_EPROM_VERSION Incorrect Eprom version in MVS* 1
511004 FM_VIS_E1 VS: Unknown request* 1
511005 FM_VIS_E2 VS: Data not correct during request* 1
511006 FM_VIS_E3 VS: Check sum error during data
transmission*
1
511007 FM_VIS_E4 VS: Reference No. unknown, model
not found*
1
511008 FM_VIS_E5 VS: Incorrect parameters during
request*
1
511009 FM_VIS_E6 VS: Not enough memory for a window
definition*
1
