GEM for SIPLACE V5.01 Page 204 of 252 ©Siemens AG, all rights reserved CEID Nam e Descript ion 511010 FM_VIS_E7 VS: Not enough mem ory for a definition* 1 511012 FM_VIS_E8 VS: Not enough mem ory for im age* 1 511013 FM_V…

GEM for SIPLACE V5.01

CEID Name Description

the operator saves the modified data.

411001 FM_LAGE_DETERMINANTE 94 DETERMINANT not correct during

position recognition*

411002 FM_LAGE_MARKE_FEHLT 95 Fiducial missing in position

recognition*

411003 FM_LAGE_KORR_ANFAHREN 96 CORR_MOVE not correct during

position recognition*

411004 FM_LAGE_MARKEN_ART Fiducial type (fid/ink spot) not correct* 1

411005 FM_FLE_N_MOEGL Limited conveyor position recognition* 1

411006 FM_FLE_N_MOEGL_SPUR Conveyor position recognition not

possible*

411007 FM_FOERD_MARKE_FEHLT feeder fiducial not found* 1

411008 FM_WPW_MARKE_FEHLT wafffle pack changer fiducial not

found*

411009 FM_PORTALUNRUHE_X X-axis moving during measurement* 1

411010 FM_PRTALUNRUHE_Y Y-axis moving during measurement* 1

* Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these fiducials

collection events.

9LVLRQ

CEID Name Description

510001 PackFormModified <MODIFIEDPACKAGEFORM> was

modified at the station. The Event

occurs when the operator saves the

modified data.*

511001 FM_INIT_HS3L Error during MVS-initialization via

HS3L*

511002 FM_ANZ_FOV Component too large for opt. multiple

measurement*

511003 FM_MVS_EPROM_VERSION Incorrect Eprom version in MVS* 1

511004 FM_VIS_E1 VS: Unknown request* 1

511005 FM_VIS_E2 VS: Data not correct during request* 1

511006 FM_VIS_E3 VS: Check sum error during data

transmission*

511007 FM_VIS_E4 VS: Reference No. unknown, model

not found*

511008 FM_VIS_E5 VS: Incorrect parameters during

request*

511009 FM_VIS_E6 VS: Not enough memory for a window

definition*

GEM for SIPLACE V5.01

CEID Name Description

511010 FM_VIS_E7 VS: Not enough memory for a

definition*

511012 FM_VIS_E8 VS: Not enough memory for image* 1

511013 FM_VIS_EA VS: a request is now being

processed*

511014 FM_VIS_EB VS: Request cannot be finished and is

being aborted*

511015 FM_VIS_EC VS: Hardware error in vision system

(FATAL ERROR) *

511016 FM_VIS_DUMMY_ED undefined error number from MVS

(ED) *

511017 FM_VIS_EE VS: No reaction from M0 (reset

M10000) *

511018 FM_VIS_DUMMY_EF undefined error number from MVS

(EF) *

521019 F_MAX_GRAD VS: Maximal gradient number of

fiducal profile exceeded*

521020 F_VS_GLK_NOK VS: Communication between SR and

MC defective*

521021 F_CODE_UNBEKANNT VS: Unknown message code* 1

521022 F_DAT_OEFFNEN VS: File could not be opened* 1

521023 F_MK_DATEN VS: Error in fiducial data* 1

521024 F_CRUN_MALLOC VS: Error during memory request* 1

521025 F_CRUN_FOPEN VS: File could not be opened* 1

521026 F_FKT_SENDSR VS: Error in send function in SC* 1

521027 F_ZUSTAND_UNBEKANNT VS: Unknown state* 1

521028 F_SUCH_UPLOAD VS: Upload data incorrect* 1

521029 F_VS_KEIN_INDEX VS: Search for array index not

successful*

511030 FM_OPT_OHNE_RESULT Vision system not providing meas.

results*

511031 FM_OPT_TEILUNGS_KONTR Spacing of a pin group outside

tolerance*

511032 FM_OPT_LEAD_TIP_NK Lead tip: component outside

tolerance*

511033 FM_OPT_LEAD_TIP_NV Lead tip: evaluation not possible* 1

511034 FM_OPT_LEAD_TIP_NR Lead tip: no result* 1

511035 FM_OPT_LAGE_X_TOL_DEF Component outside feed tolerance* 1

511036 FM_OPT_LAGE_X_TOL_S Component outside feed tolerance

(size) *

511037 FM_OPT_LAGE_X_TOL_R Component outside feed tolerance

(row) *

GEM for SIPLACE V5.01

CEID Name Description

511038 FM_OPT_LAGE_X_TOL_C Component outside feed tolerance

(corner) *

511039 FM_OPT_LAGE_X_TOL_L Component outside feed tolerance

(lead) *

511040 FM_OPT_LAGE_X_TOL_G Component outside feed tolerance

(grid) *

511041 FM_OPT_LAGE_X_TOL_B Component outside feed tolerance

(ball) *

511042 FM_OPT_LAGE_Y_TOL_DEF Component outside feed tolerance* 1

511043 FM_OPT_LAGE_Y_TOL_S Component outside feed tolerance

(size) *

511044 FM_OPT_LAGE_Y_TOL_R Component outside feed tolerance

(row) *

511045 FM_OPT_LAGE_Y_TOL_C Component outside feed tolerance

(corner) *

511046 FM_OPT_LAGE_Y_TOL_L Component outside feed tolerance

(lead) *

511047 FM_OPT_LAGE_Y_TOL_B Component outside feed tolerance

(ball) *

511048 FM_OPT_LAGE_Y_TOL_G Component outside feed tolerance

(grid) *

511049 FM_OPT_QUAL_FAKTOR_DEF Quality too low during optical

centering*

511050 FM_OPT_QUAL_FAKTOR_S Quality too low during opt. centering

(s) *

511051 FM_OPT_QUAL_FAKTOR_R Quality too low during opt. centering

(r) *

511052 FM_OPT_QUAL_FAKTOR_C Quality too low during opt. centering

511053 FM_OPT_QUAL_FAKTOR_L Quality too low during opt. centering (l)

511054 FM_OPT_QUAL_FAKTOR_G Quality too low during opt. centering

(g) *

511055 FM_OPT_QUAL_FAKTOR_B Quality too low during opt. centering

(b) *

511056 FM_OPT_DIM_L_TOL_DEF Component length outside tolerance* 1

511057 FM_OPT_DIM_L_TOL_S Component length outside tolerance

(s) *

511058 FM_OPT_DIM_L_TOL_R Component length outside tolerance

(r) *

511059 FM_OPT_DIM_L_TOL_C Component length outside tolerance

511060 FM_OPT_DIM_L_TOL_L Component length outside tolerance

(l) *

511061 FM_OPT_DIM_L_TOL_G Component length outside tolerance 1
