GEM for SIPLACE V5.01 Page 210 of 252 ©Siemens AG, all rights reserved CEID Nam e Descript ion 611002 FM_TSP_EBLS_NBED T he input conveyor light barrier is not covered* 1 611003 FM_TSP_EBLS_NFREI T he input conveyor ligh…

GEM for SIPLACE V5.01

CEID Name Description

tol. *

511144 FM_OPT_BEIN_NK_C No. of pins: cmpnt outside feed tol. (c)

511145 FM_OPT_BEIN_NK_L No. of pins: cmpnt outside feed tol. (l)

511146 FM_OPT_REIH_NK_DEF Colinearity: cmpnt. outside feed

tolerance*

511147 FM_OPT_REIH_NK_C Colinearity: cmpnt. outside feed tol. (c)

511148 FM_OPT_REIH_NK_L Colinearity: cmpnt. outside feed tol. (l)

511149 FM_OPT_TEIL_NK_DEF Spacing: component outside feed

tolerance*

511150 FM_OPT_TEIL_NK_C Spacing: component outside feed tol.

511151 FM_OPT_TEIL_NK_L Spacing: component outside feed tol.

(l) *

511152 FM_MVSBILD_UPLOAD_SYST

Error upon saving the component

image*

511153 FM_MVSBILD_UPLOAD_ABSP

EICHERN

Error upon saving the MVS image to

file*

511154 FM_VS_GDH_GEM VS: Error upon initialization of GEM

functions*

511155 FM_VS_AUSWERTEZEIT VS: Max. evaluation time for optical

centering exceeded*

511156 FM_LESEN_FILE GF-file not found* 1

511157 FM_KEINE_NR_FREI MVS: name space overflow * 1

511158 FM_MESSUNG_UNVOLLSTAE

NDIG

Calibration tool not fully measured * 1

511159 FM_QUALITAET GF or Fiducial quality not sufficient* 1

511160 FM_MVS_FEHLER MVS: communication error* 1

* Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these vision

collection events.

7UDQVSRUW

CEID Name Description

611001 FM_TSP_ABGEGEBEN Interface signals to the preceding

station incorrect*

GEM for SIPLACE V5.01

CEID Name Description

611002 FM_TSP_EBLS_NBED The input conveyor light barrier is not

covered*

611003 FM_TSP_EBLS_NFREI The input conveyor light barrier is not

released*

611004 FM_TSP_KLP_IM_EB No PCB on the input conveyor* 1

611005 FM_TSP_KERAM_ZENTR_OFF

Ceramic substrate centering: x clamp

cannot be opened*

611006 FM_TSP_KERAM_ZENTR_GES

CHL

Ceramic substrate centering: x clamp

cannot be locked*

611007 FM_TSP_HUBT_UNT The lifting table cannot be moved

downwards*

611008 FM_TSP_HUBT_OB The lifting table cannot be moved

upwards*

611009 FM_TSP_MBLS_NFREI Center conveyor light barrier is not

released*

611010 FM_TSP_MBLS_NBED PCB does not reach the center

conveyor*

611011 FM_TSP_STOPPER_AUS Stopper jam during extension* 1

611012 FM_TSP_STOPPER_EIN Stopper jam during retraction* 1

611013 FM_TSP_KEINE_LP_IM_MB No PCB on the center conveyor* 1

611014 FM_TSP_ABLS_NBED PCB does not reach the output

conveyor*

611015 FM_TSP_ABLS_FBED Assignments of parallel output

conveyors not correct*

611016 FM_TSP_EB_BELEGT Input conveyor occupied* 1

611017 FM_TSP_MB_BELEGT Center conveyor occupied* 1

611018 FM_TSP_AB_BELEGT Output conveyor occupied* 1

611019 FM_LSS_PROXIMITY

SWITCH_N_BED

Proximity switch of left table side is not

activated*

611020 FM_LSS_MAX_SCHRITT Error in axis programming (left table

side) *

611021 FM_LSS_PROXIMITY

SWITCH_N_FREI

Proximity switch of left table side

responding constantly*

611022 FM_LSS_LP_IM_TSP PCB in conveyor during width

adjustment*

611023 FM_LSS_ENDSCHALT_AUS Width adjustment at limit switch

maximum width*

611024 FM_LSS_ENDSCHALT_ZU Width adjustment at limit switch

minimum width*

611025 FM_LSAUT_VERFAHRBER Conveyor belt target width outside

travel range*

611026 FM_LSAUT_TIMEOUT Conveyor belt target width cannot be

set (timeout) *

611027 FM_LSAUT_BEIDE_ENDS Both limit switches of width 1

GEM for SIPLACE V5.01

CEID Name Description

adjustment actuated*

611028 FM_LSAUT_ENDSCHALT_ZU Limit switch of width adjustment for

minimum width actuated*

611029 FM_LSAUT_ENDSCHALT_AUS Limit switch of width adjustment for

maximum width actuated*

611030 FM_LSK_MAX_SCHRITT Proximity switch not found during

conveyor belt width check*

611031 FM_LSK_PROXIMITY

SWITCH_N_FREI

Proximity switch switched before

conveyor belt width check*

610031 PCBreachedInputConveyor The light barrier of the input conveyor

signals the arrival of a PCB and

<INPUTCONVEYORSTATE> will be

updated

610032 PCBreachedCenterConveyor The light barrier of the center

conveyor signals the arrival of a PCB

,<INPUTCONVEYORSTATE> and

<CENTERCONVEYORSTATE> will

be updated

610033 PCBreachedOutputConveyor The light barrier of the output

conveyor signals the arrival of a PCB,

<CENTERCONVEYORSTATE> and

<OUTPUTCONVEYORSTATE> will

be updated

610034 PCBreachedInputConveyor2 The light barrier of the input conveyor

on twin side signals the arrival of a

PCB and

will be updated

610035 PCBreachedCenterConveyor2 The light barrier of the center

conveyor on twin side signals the

arrival of a PCB,

and

will be updated

610036 PCBreachedOutputConveyor2 The light barrier of the output

conveyor on twin side signals the

arrival of a PCB,

and

will be updated

610037 TransportWidthMeasured The SIPLACE finished the

measurement of the

610038 StopperUp Stopper up 1

610039 StopperDown Stopper down 1

610040 LiftTableUp Lifting table up 1

610041 LiftTableDown Lifting table down 1
