GEM for SIPLACE V5.01

CEID Name Description

610042 CerCenterUp Ceramic substrate centering up 1

610043 CerCenterDown Ceramic substrate centering down 1

610044 TransportWidthMeasured2 The SIPLACE finished the

measurement of the

<TWINTRANSPORTWIDTH>on twin

side

610045 StopperUp2 Stopper up on twin side 1

610046 StopperDown2 Stopper down on twin side 1

610047 LiftTableUp2 Lifting table up on twin side 1

610048 LiftTableDown2 Lifting table down on twin side 1

610049 CerCenterUp2 Ceramic substrate centering up on

twin side

610050 CerCenterDown2 Ceramic substrate centering down on

twin side

610051 TakeOutInConv A PCB was taken out of the input

conveyor and

<INPUTCONVEYORSTATE> will be

updated

610052 TakeOutOutConv A PCB was taken out of the output

conveyor and

<OUTPUTCONVEYORSTATE> will

be updated

610053 TakeOutInConv2 A PCB was taken out of the input

conveyor on twin side and

will be updated

610054 TakeOutOutConv2 A PCB was taken out of the output

conveyor on twin side and

will be updated

611055 FM_BRV_AUT_SYN Autom. width adjustment not possible

in SYNCHRONOUS transport mode

611056 FM_BRV_SUCH_VER Conveyor belt width out of travel range 1

611057 FM_TSP_ABLS_NFREI Sensor of the output conveyor not

released

611058 FM_TSP_ANGEKOMMEN next station can’t take over PCB 1

* Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these fiducials

collection events.

&RSODQDULW\

CEID Name Description

GEM for SIPLACE V5.01

CEID Name Description

711001 FM_CO_Z_KLEMMUNG Coplanarity: Clamping of Z-axis does

not work*

711002 FM_CO_INIT Coplanarity module cannot be

initialized*

711003 FM_CO_KOMM_TIMEOUT Timeout during reception from

coplanarity*

711004 FM_CO_KOMM_CHK_NOK Check sum error of answer from

coplanarity*

711005 FM_CO_KOMM_STX Answer from coplanarity has no STX* 1

711006 FM_CO_KOMM_OVERFLOW Coplan.: Communication buffer

overflow on MC*

711007 FM_CO_KOMM_RIO_FEHLER Coplan.: Software error during system

call RIO*

711008 FM_CO_BEFEHL_NAUSF Coplanarity cannot execute

command*

711009 FM_CO_BEFEHL_NVOLLST Command to coplanarity is not

complete*

711010 FM_CO_BE_DSC_NVOLLST Component description of coplanarity

is not complete*

711011 FM_CO_DATEN_WERT_UNG Coplan.: Data value outside of range* 1

711012 FM_CO_DATEN_FORMAT_UN

Command data format to coplanarity

is invalid*

711013 FM_CO_LOETPASTE_NULL Coplanarity tolerance is zero* 1

711014 FM_CO_KOMM_FEHLER Undefined error message* 1

711015 FM_CO_CHKSUM Check sum error of coplanarity* 1

711016 FM_CO_BREAK Coplanarity has received a hardware

break*

711017 FM_CO_KEIN_STX Message to coplanarity has no STX* 1

711018 FM_CO_ID_UNBEK Undefined error message* 1

711019 FM_CO_P_ID_UNBEK Coplan.: Parameter number unknown* 1

711020 FM_CO_READ_PARAM Coplan.: Attempt to modifify a Read

Only Para*

711021 FM_CO_ANZ_GRP_GROSS Coplan.: Component description has

too many groups*

711022 FM_CO_BE_ID_UNBEK Coplan.: Component number invalid* 1

711023 FM_CO_BE_NAKTUELL Coplan.: Component will not be

processed*

711024 FM_CO_BE_ID_NVORH Coplan.: Component not loaded* 1

711025 FM_CO_R_ID_UNBEK Coplan.: Row number invalid* 1

711026 FM_CO_R_ID_NAKTUELL Coplan.: Row number will not be

processed*

711027 FM_CO_R_ID_NVORH Coplan.: Row not available* 1

GEM for SIPLACE V5.01

CEID Name Description

711028 FM_CO_BEIN_ZUVIEL Coplan.: Too many pins measured* 1

711029 FM_CO_MEM_OVERFLOW Undefined error message 1

711030 FM_CO_KOMM_BUFFER_VOL

Message to coplanarity too long* 1

711031 FM_CO_MESSD_BUFFER_VO

Coplan.: Measuring data buffer is full* 1

711032 FM_CO_GRP_POOL_LEER Coplan.: Memory for group description

full*

711033 FM_CO_GF_POOL_LEER Coplan.: Memory for package form

description full*

711034 FM_CO_MATH_FEHLER Undefined error message 1

711035 FM_CO_DIV_NULL Coplan.: Division by zero* 1

711036 FM_CO_MESSBER_UNG Undefined error message 1

711037 FM_CO_BE_MESSBEREICH Coplan.: Component outside of

measuring range*

711038 FM_CO_BEIN_FEHLT Coplan.: One pin of component

missing*

711039 FM_CO_MESSDAT_UNVOLL Coplan.: Measuring on one pin

finished*

711040 FM_CO_BEIN_DEFEKT Coplan.: Pin outside of coplan.

position tolerance*

711041 FM_CO_AUSW_ABGEB Coplan.: Placement level not found* 1

711042 FM_CO_FF_FHL Undefined error message 1

711043 FM_CO_FF_FHL_CCD Coplanarity module defective; replace

and boot*

711044 FM_CO_FF_FHL_SCAN_STAR

Coplanarity module defective; replace

and boot*

711045 FM_CO_FF_FHL_SCAN_ENDE Coplanarity module defective; replace

and boot*

711046 FM_CO_FF_FHL_SKAL Coplanarity module defective; replace

and boot*

711047 FM_CO_FF_FHL_MAX_DIG Coplanarity module defective; replace

and boot*

711048 FM_CO_FF_FHL_C_CODE Software error in coplanarity module;

boot*

711049 FM_CO_EXIT_PROG Coplan.: Command Quit sent* 1

711050 FM_CO_BE_SCHLECHT Coplanarity: Bad component, to be

returned*

711051 FM_COPL_SPURLEER Track empty due to coplanarity error* 1

711052 FM_CO_N_MESSBAR component was not measured: offset

too big*

711053 FM_KOP_KOMM Coplan: communications error* 1

711054 FM_KOP_GROB Coplan: z-position outside measuring 1
