GEM for SIPLACE V5.01

CEID Name Description

range, invalid measured value*

711055 FM_KOP_RESET Coplan: error upon reset* 1

711056 FM_KOP_VERSION Coplan: incorrect version* 1

711057 FM_KOP_DURCHM Coplan: incorrect diameter of

calibration tool*

711058 FM_KOP_KANTE Coplan: edge of calibration tool not

found*

* Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these coplanarity

collection events.

:DIIOH3DFN&KDQJHU

CEID Name Description

810001 WPCtrayChanged WPC tray changed 1

810002 WPCtransPos WPC in transport position 1

810003 WPCrefillPos WPC in refill position 1

810004 WPCrefillCheck WPC refill check finished 1

810005 WPCrefRun WPC reference run completed and

<SOFTWAREREVWPC> updated

810006 WPCsetUpLoad Setup loaded on WPC 1

810007 WPCinvetStatus <INVENTARYWPC> status received

form WPC

811001 FM_WPW_RIO Communication with wafflepack

changer faulty*

811002 FM_WAG_DUMMY_E0_OK undefined error number from trolley

(E0) *

811003 FM_WAG_CHECKSUMME Check sum error in communication

with table*

811004 FM_WP_SYNTAX Syntax error in command to

component table*

811005 FM_WAG_CODE_LOST Program loss of table or trolley

control*

811006 FM_WAG_RAM_DEFEKT RAM of trolley control defective* 1

811007 FM_WP_REFER Command not executed, component

table not referred*

811008 FM_WP_NACHF Command not executed, component

table in refill position*

811009 FM_WP_RAHMEN WPC: No tray available* 1

811010 FM_WP_RUESTUNG_Q WPC: Sent set-up contains errors* 1

811011 FM_WP_SPEICHER WPC: Data loss in component table 1

GEM for SIPLACE V5.01

CEID Name Description

(defective battery) *

811012 FM_WP_TIMEOUT_T WPC: Fault in feed axis (Servo or

axis card) *

811013 FM_WP_ENDSCH_T WPC: Feed axis at limit switch* 1

811014 FM_WP_ACHSE_T WPC: Axis error of feed axis* 1

811015 FM_WP_SCHALTER_T WPC: Feed axis servo released* 1

811016 FM_WP_ZANGE WPC: Error in jaw position* 1

811017 FM_WP_TIMEOUT_P WPC: Fault in lifting axis (Servo or

axis card) *

811018 FM_WP_ENDSCH_P WPC: Lifting axis at limit switch* 1

811019 FM_WP_ACHSE_P WPC: Axis error of lifting axis* 1

811020 FM_WP_SCHALTER_P WPC: Lifting axis servo released* 1

811021 FM_WP_STEUERUNG WPC: Control switched off* 1

811022 FM_WP_SCHUTZ WPC: Protection at component table

open*

811023 FM_WP_TRANSP WPC: Error while transporting tray* 1

811024 FM_WP_RUESTUNG WPC: Error in saved set-up* 1

811025 FM_WP_FEHLT WPC: One tray of saved set-up

missing*

811026 FM_WP_MAGAZIN WPC: When returning tray, level

occupied*

811027 FM_WP_VERSCHW WPC: Tray has been taken out* 1

811028 FM_WP_UEBERG WPC: Take-over position already

occupied*

811029 FM_WP_VERDREHT WPC: Tray in incorrect pos. or

protection not closed properly*

811030 FM_WP_SICHERUNG WPC: Feed axis has touched

protection*

811031 FM_WPW_NFPOS WPC must be moved from refill

position*

811032 FM_WP_WRITE_HD Error while writing WPC machine data

to hard disk*

811033 FM_WP_READ_HD Error while reading WPC machine

data from hard disk*

811034 FM_WP_WRITE_FD Error while writing WPC machine data

to floppy*

811035 FM_WP_READ_FD Error while reading WPC machine

data from floppy*

811036 FM_WP_ANSCHLAG limit switch not found* 1

811037 FM_WP_CHECKSUMME checksum error* 1

811038 FM_WPW error* 1

811039 FM_WP_NULLKORR distance between zero point of WPC 1

GEM for SIPLACE V5.01

CEID Name Description

axis and reference BERO to small*

811040 FM_WP_80F3_MA error reading standard machine data

for WPC*

* Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these waffle pack

changer collection events.

%DUFRGH

CEID Name Description

RPT

920001 BCread The barcode reader transmits a

barcode <BCININPUTCONVEYOR>

920002 ComponentBCread A component barcode is read via the

GUI.

920011 BCTwinRead The barcode reader transmits a

barcode

<BCINTWININPUTCONVEYOR> from

the twin conveyor.

921001 FM_LP_BC_NOK PCB barcode: incorrect format* 1

921002 FM_LP_BC_KEINE_DAT No data received from PCB barcode

reader*

921003 FM_BC_ZU_LANG Barcode too long, cut off! * 1

921004 FM_BL_INPUT_NOK BL: unexpected input* 1

921005 FM_LP_KEIN_BC No PCB barcode read* 1

921006 FM_GK_LR_DURCHTRANSP Caution: PCB transported through by

line computer*

* Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these barcode

collection events.

*(0.HUQHO

&(,' 1DPH 'HVFULSWLRQ

1000001 EqConstChange Equipment constant changed at the

machine

1000002 S10Ack 1

Communication Model

Control State Model

1000003 GemControlStateLOCAL SIPLACE goes to local mode 0

1000004 GemControlStateREMOTE SIPLCAE goes to remote mode 0

1000005 GemEquipmentOFFLINE SIPLACE goes OFFLINE 0
