GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 217 of 252
CEID Name Description
axis and reference BERO to small*
811040 FM_WP_80F3_MA error reading standard machine data
for WPC*
1
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these waffle pack
changer collection events.
%DUFRGH
CEID Name Description
RPT
920001 BCread The barcode reader transmits a
barcode <BCININPUTCONVEYOR>
24
920002 ComponentBCread A component barcode is read via the
GUI.
27
920011 BCTwinRead The barcode reader transmits a
barcode
<BCINTWININPUTCONVEYOR> from
the twin conveyor.
30
921001 FM_LP_BC_NOK PCB barcode: incorrect format* 1
921002 FM_LP_BC_KEINE_DAT No data received from PCB barcode
reader*
1
921003 FM_BC_ZU_LANG Barcode too long, cut off! * 1
921004 FM_BL_INPUT_NOK BL: unexpected input* 1
921005 FM_LP_KEIN_BC No PCB barcode read* 1
921006 FM_GK_LR_DURCHTRANSP Caution: PCB transported through by
line computer*
1
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these barcode
collection events.
*(0.HUQHO
&(,' 1DPH 'HVFULSWLRQ
1000001 EqConstChange Equipment constant changed at the
machine
0
1000002 S10Ack 1
Communication Model
Control State Model
1000003 GemControlStateLOCAL SIPLACE goes to local mode 0
1000004 GemControlStateREMOTE SIPLCAE goes to remote mode 0
1000005 GemEquipmentOFFLINE SIPLACE goes OFFLINE 0
GEM for SIPLACE V5.01
Page 218 of 252 ©Siemens AG, all rights reserved
&(,' 1DPH 'HVFULSWLRQ
1000006 GemControlStateOFFLINE Control state goes to OFFLINE 0
1000018 ControlModeChanged <CONTROLMODE> state changed
(LCU, GEM-Host, Stand-alone)
0
1000019 OperatorCommand The operator issued a „host -
available“ command while the
SIPLACE is in Remote mode.
1
Spooling
1000007 GemSpoolingActivated Spooling is activated. This event is
never reported directly to the host,
but instead is directed as the first
message to the spool file
0
1000008 GemSpoolingDeactivated The spool area has been completely
emptied.
0
1000009 GemSpoolTransmitFailure Communication error during
transmitting spooled messages to
host. This event is never reported
directly to the host, but instead it is
directed to the end of the spool file
0
Process State Model
1000010 Init2Process The Siplace change its processing
state from „Machine Initialization“ to
„Processing“
1
1000011 Process2Init The Siplace change its processing
state from „Processing“ to „Machine
Initialization“
1
1000012 Process2SingleFunction The Siplace change its processing
state from „Processing“ to „Single
Function“
1
1000013 SingleFunction2Process The Siplace change its processing
state from „Single Function“ to
„Processing“
1
1000014 Init2SingleFunction The Siplace change its processing
state from „Machine Initialization“ to
„Single Function“
1
1000015 SingleFunction2Init The Siplace change its processing
state from „Single Function“ to
„Machine Initialization“
1
Process Program Management
1000016 GemPPChangeEvent Program changed at the machine 1
1000017 GemBadDownloadEvent Error in downloaded program 1
1001018 FM_GEM_INIT GEM: Error upon initialization of
GEM interface to host*
1
1001019 FM_GEM_INIT_MC GEM: Error upon initialization of
interface to MC*
1
1001020 FM_GEM_INIT_GUI GEM: Error upon initialization of
interface to user interface*
1
1001021 FM_GEM_SIPLACE GEM: Error in SIPLACE GEM 1
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 219 of 252
&(,' 1DPH 'HVFULSWLRQ
software*
1001022 FM_GEM_OP_MELDUNG GEM: Most recent operator
message could not be sent to the
host*
1
1001023 FM_GEM_VERB_GUI GEM: Faulty connection between
GEM interface and user interface*
1
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these GEM-
kernel collection events.
2SHUDWRU
&(,' 1DPH 'HVFULSWLRQ
1120001 EmergencyStop Emergency stop pressed 1
1120002 StopButton Stop button pressed 1
1120003 StartButton Start button pressed 1
1120007 GUIStart Message from GUI: Start. 1
1120008 GUISTOP Message from GUI: Stop. 1
1120009 GUIContinue Message from GUI: Continue. 1
1120010 GUIAbort Message from GUI: Abort. 1
1120011 GUISingleFuncGan1 Message from GUI: Entry single
function gantry 1
1
1120012 GUISingleFuncGan2 Message from GUI: Entry single
function gantry 2
1
1120013 GUITransportFunc Message from GUI: Entry transport
function
1
1120014 GUIFiducialTeach Message from GUI: Entry fiducial
teaching
1
1120015 GUIPackageForm Message from GUI: Entry package
form modification
1
1120016 GUIwithoutLCU Message from GUI: Running without
LCU
1
1120017 GUILoadPP Message from GUI: Load Placement
Program
1
1120018 GUIPassThrough Message from GUI: PCB-Barcode
error „pass through“
1
1120019 GUIRemovePCB Message from GUI: PCB-Barcode
error „remove PCB“
1
1120020 GUIBCbyKeyboard Message from GUI: PCB-Barcode
entered by keyboard
1
1120021 GUIReqMaOption Message from GUI: Request machine
options
1
1120022 GUIReqMaConf Message from GUI: Request machine 1
