GEM for SIPLACE V5.01 Page 220 of 252 ©Siemens AG, all rights reserved &(,' 1DPH 'HVFULSWLRQ configur ation 1120023 G UISetMaOption Message f rom GUI: Set m achine options 1 1120024 G UISingleStepOn Message…

100%1 / 245
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 219 of 252
&(,' 1DPH 'HVFULSWLRQ
software*
1001022 FM_GEM_OP_MELDUNG GEM: Most recent operator
message could not be sent to the
host*
1
1001023 FM_GEM_VERB_GUI GEM: Faulty connection between
GEM interface and user interface*
1
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these GEM-
kernel collection events.
2SHUDWRU
&(,' 1DPH 'HVFULSWLRQ
1120001 EmergencyStop Emergency stop pressed 1
1120002 StopButton Stop button pressed 1
1120003 StartButton Start button pressed 1
1120007 GUIStart Message from GUI: Start. 1
1120008 GUISTOP Message from GUI: Stop. 1
1120009 GUIContinue Message from GUI: Continue. 1
1120010 GUIAbort Message from GUI: Abort. 1
1120011 GUISingleFuncGan1 Message from GUI: Entry single
function gantry 1
1
1120012 GUISingleFuncGan2 Message from GUI: Entry single
function gantry 2
1
1120013 GUITransportFunc Message from GUI: Entry transport
function
1
1120014 GUIFiducialTeach Message from GUI: Entry fiducial
teaching
1
1120015 GUIPackageForm Message from GUI: Entry package
form modification
1
1120016 GUIwithoutLCU Message from GUI: Running without
LCU
1
1120017 GUILoadPP Message from GUI: Load Placement
Program
1
1120018 GUIPassThrough Message from GUI: PCB-Barcode
error „pass through“
1
1120019 GUIRemovePCB Message from GUI: PCB-Barcode
error „remove PCB“
1
1120020 GUIBCbyKeyboard Message from GUI: PCB-Barcode
entered by keyboard
1
1120021 GUIReqMaOption Message from GUI: Request machine
options
1
1120022 GUIReqMaConf Message from GUI: Request machine 1
GEM for SIPLACE V5.01
Page 220 of 252 ©Siemens AG, all rights reserved
&(,' 1DPH 'HVFULSWLRQ
configuration
1120023 GUISetMaOption Message from GUI: Set machine
options
1
1120024 GUISingleStepOn Message from GUI: Set single step
mode on
1
1120025 GUISingleStepOff Message from GUI: Set single step
mode off
1
1120026 GUITableProgDownload Message from GUI: Table program
download
1
1120027 GUIAllTrackRefill Message from GUI: Set all tracks
refilled and <GUITRACKNR> will be
updated
1
1120028 GUITrackRefill Message from GUI: Set
<GUITRACKNR> refilled
1
1120029 GUIFeederBankRefill Message from GUI: Set feeder bank
refilled and <GUITRACKNR> will be
updated
1
1120030 GUILinearFeederOn Message from GUI: Vibrate linear
feeders ON and <GUITRACKNR> will
be updated
1
1120031 GUILinearFeederOff Message from GUI: Vibrate linear
feeders OFF and <GUITRACKNR>
will be updated
1
1120032 GUIReqInvenWPC Message from GUI: Request WPC
inventory status and <GUITRACKNR>
will be updated
1
1120033 GUIReqMaxWPC Message from GUI: Request WPC
maximum fill stand and
<GUITRACKNR> will be updated
1
1120034 GUISetInvenWPC Message from GUI: Set WPC
inventory status and <GUITRACKNR>
will be updated
1
1120035 GUIReqConfWPC Message from GUI: Request WPC
configuration
1
1120036 GUIRefillPosWPC Message from GUI: WPC to refill
position
1
1120037 GUIContinueWPC Message from GUI: WPC continue
(leave refill position)
1
1120038 GUITransportWPC Message from GUI: WPC to transport
position
1
1120039 GUIRefRunWPC Message from GUI: WPC reference
run
1
1120040 GUIReqTrayWPC Message from GUI: WPC request tray 1
1120041 GUIImageGan1On Message from GUI: Image from
camera at gantry 1 ON
1
1120042 GUIImageGan1Off Message from GUI: Image from
camera at gantry 1 OFF
1
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 221 of 252
&(,' 1DPH 'HVFULSWLRQ
1120043 GUIImageGan2On Message from GUI: Image from
camera at gantry 2 ON
1
1120044 GUIImageGan2Off Message from GUI: Image from
camera at gantry 2 OFF
1
1120045 GUIRevolverStep Message from GUI: Step to next
revolver position and
<GUIGANTRYNR> will be updated
1
1120046 GUIRevPos1 Message from GUI: Revolver to
position 1 and <GUIGANTRYNR> will
be updated
1
1120047 GUIHeadRefRun Message from GUI: Head reference
run and <GUIGANTRYNR> will be
updated
1
1120048 GUIReqRevPos Message from GUI: Request revolver
position and <GUIGANTRYNR> will
be updated
1
1120049 GUIActuateDP Message from GUI: Actuate dp-axis
and <GUIGANTRYNR> will be
updated
1
1120050 GUIComAirPickUp Message from GUI: Compressed air
at pick-up position and
<GUIGANTRYNR> will be updated
1
1120051 GUIVacPickUp Message from GUI: Vacuum at pick-
up position and <GUIGANTRYNR>
will be updated
1
1120052 GUIComAirPlace Message from GUI: Compressed air
at placement position and
<GUIGANTRYNR> will be updated
1
1120053 GUIVacPlace Message from GUI: Vacuum at
placement position and
<GUIGANTRYNR> will be updated
1
1120054 GUIMeaVacPickUp Message from GUI: Measure vacuum
at pick-up position
1
1120055 GUIMeaComAirPickUp Message from GUI: Measure
compressed air at pick-up position
1
1120056 GUIMeaVacHold Message from GUI: Measure vacuum
in the holding circuit
1
1120057 GUIMeaNozOffset Message from GUI: Measure nozzle
offset and <GUIGANTRYNR> will be
updated
1
1120058 GUIReqVacAllNozzle Message from GUI: Request vacuum
for all nozzle at the revolver and
<GUIGANTRYNR> will be updated
1
1120059 GUIReqNozConf Message from GUI: Request current
nozzle configuration and
<GUIGANTRYNR> will be updated
1
1120060 GUIReqReqNozConf Message from GUI: Request required
nozzle configuration and
1
