GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 221 of 252
&(,' 1DPH 'HVFULSWLRQ
1120043 GUIImageGan2On Message from GUI: Image from
camera at gantry 2 ON
1
1120044 GUIImageGan2Off Message from GUI: Image from
camera at gantry 2 OFF
1
1120045 GUIRevolverStep Message from GUI: Step to next
revolver position and
<GUIGANTRYNR> will be updated
1
1120046 GUIRevPos1 Message from GUI: Revolver to
position 1 and <GUIGANTRYNR> will
be updated
1
1120047 GUIHeadRefRun Message from GUI: Head reference
run and <GUIGANTRYNR> will be
updated
1
1120048 GUIReqRevPos Message from GUI: Request revolver
position and <GUIGANTRYNR> will
be updated
1
1120049 GUIActuateDP Message from GUI: Actuate dp-axis
and <GUIGANTRYNR> will be
updated
1
1120050 GUIComAirPickUp Message from GUI: Compressed air
at pick-up position and
<GUIGANTRYNR> will be updated
1
1120051 GUIVacPickUp Message from GUI: Vacuum at pick-
up position and <GUIGANTRYNR>
will be updated
1
1120052 GUIComAirPlace Message from GUI: Compressed air
at placement position and
<GUIGANTRYNR> will be updated
1
1120053 GUIVacPlace Message from GUI: Vacuum at
placement position and
<GUIGANTRYNR> will be updated
1
1120054 GUIMeaVacPickUp Message from GUI: Measure vacuum
at pick-up position
1
1120055 GUIMeaComAirPickUp Message from GUI: Measure
compressed air at pick-up position
1
1120056 GUIMeaVacHold Message from GUI: Measure vacuum
in the holding circuit
1
1120057 GUIMeaNozOffset Message from GUI: Measure nozzle
offset and <GUIGANTRYNR> will be
updated
1
1120058 GUIReqVacAllNozzle Message from GUI: Request vacuum
for all nozzle at the revolver and
<GUIGANTRYNR> will be updated
1
1120059 GUIReqNozConf Message from GUI: Request current
nozzle configuration and
<GUIGANTRYNR> will be updated
1
1120060 GUIReqReqNozConf Message from GUI: Request required
nozzle configuration and
1
GEM for SIPLACE V5.01
Page 222 of 252 ©Siemens AG, all rights reserved
&(,' 1DPH 'HVFULSWLRQ
<GUIGANTRYNR> will be updated
1120061 GUISetNozConf Message from GUI: Set nozzle
configuration state to OK,
<GUIGANTRYNR> and
<GUISEGMENTNR> will be updated
1
1120062 GUIReqNozChaConf Message from GUI: Request nozzle
changer configuration and
<GUIGANTRYNR> will be updated
1
1120063 GUIConNozChaConf Message from GUI: Confirm nozzle
changer configuration and
<GUIGANTRYNR> will be updated
1
1120064 GUISetNozChaRefill Message from GUI: Set nozzle
changer state to refilled and
<GUIGANTRYNR> will be updated
1
1120065 GUIICHeadRefRun Message from GUI: IC head reference
run
1
1120066 GUITurnDonIC Message from GUI: Turn d-axis on IC-
head
1
1120067 GUIZaxisOn Message from GUI: Activate z-axis
clamping on IC-head
1
1120068 GUIZaxisOff Message from GUI: Deactivate z-axis
clamping on IC-head
1
1120069 GUIComAirOn Message from GUI: IC-Head
Compressed air ON
1
1120070 GUIComAirOff Message from GUI: IC-Head
Compressed air OFF
1
1120071 GUIVacOn Message from GUI: IC-Head Vacuum
ON
1
1120072 GUIVacOff Message from GUI: IC-Head Vacuum
OFF
1
1120073 GUIStoreNozzle Message from GUI: Store nozzle in
nozzle changer
1
1120074 GUIPickUpNoz Message from GUI: Pick-up Nozzle 1
1120075 GUIMeaVac Message from GUI: Measure vacuum 1
1120076 GUIReqNoz Message from GUI: Request nozzle
on IC-Head
1
1120077 GUINozChaConfIC Message from GUI: Request nozzle
changer configuration for IC-Head
1
1120078 GUIConNozChaConfIC Message from GUI: Confirm nozzle
changer configuration for IC-Head
1
1120079 GUIGanSerPos Message from GUI: Move gantry to
service position and
<GUIGANTRYNR> will be updated
1
1120080 GUIGanWaitPos Message from GUI: Move gantry to
waiting position and
<GUIGANTRYNR> will be updated
1
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 223 of 252
&(,' 1DPH 'HVFULSWLRQ
1120081 GUIGanToZero Message from GUI: Move gantry to
zero point and <GUIGANTRYNR> will
be updated
1
1120082 GUIGanRefRun Message from GUI: Gantry reference
run and <GUIGANTRYNR> will be
updated
1
1120083 GUIPCBtoCenter Message from GUI: Move PCB in the
center conveyor
1
1120084 GUIPCBtoOutput Message from GUI: Move PCB in the
output conveyor
1
1120085 GUIStopper Message from GUI: Actuate stopper 1
1120086 GUILiftingTable Message from GUI: Actuate lifting
table
1
1120087 GUITransSlow Message from GUI: Transport slow 1
1120088 GUITransFast Message from GUI: Transport fast 1
1120089 GUITransStop Message from GUI: Transport stop 1
1120090 GUIReqTransState Message from GUI: Request transport
state
1
1120091 GUITransWiderSlow Message from GUI: Transport wider
slow
1
1120092 GUITransWiderFast Message from GUI: Transport wider
fast
1
1120093 GUITransNarSlow Message from GUI: Transport
narrower slow
1
1120094 GUITransNarFast Message from GUI: Transport
narrower fast
1
1120095 GUIMeaTransWidth Message from GUI: Measure
transport width
1
1120096 ToGUInNewSetUo Message to GUI: NewSetUp 1
1120097 ToGUIPPname Message to GUI: Placement Program
Name
1
1120098 ToGUIActionText Message to GUI: Send
<GUIACTIONTEXT>
1
1120099 ToGUIClrActionText Message to GUI: Clear
<GUIACTIONTEXT>
1
1120100 ToGUIStateText Message to GUI: Send
<GUISTATETEXT>
1
1120101 ToGUIWaitMaData Message to GUI: Waiting for machine
data
1
1120102 ToGUIRefRunComplete Message to GUI: Reference run
completed
1
1120103 ToGUIMachineReady Message to GUI: Machine ready to
process
1
1120104 ToGUIStopButton Message to GUI: Stop button pressed 1
