GEM for SIPLACE V5.01 ©Siemens AG, all rights r eserved page 227 of 252 &(,' 1DPH 'HVFULSWLRQ 1120185 RepG UIMeaVac Reply to GU I: Measure vacuum 1 1120186 RepG UIReqNoz Reply to GUI: Request nozz le on IC-…

100%1 / 245
GEM for SIPLACE V5.01
Page 226 of 252 ©Siemens AG, all rights reserved
&(,' 1DPH 'HVFULSWLRQ
1120160 RepGUIComAirPickUp Reply to GUI: Compressed air at
pick-up position
1
1120161 RepGUIVacPickUp Reply to GUI: Vacuum at pick-up
position
1
1120162 RepGUIComAirPlace Reply to GUI: Compressed air at
placement position
1
1120163 RepGUIVacPlace Reply to GUI: Vacuum at placement
position
1
1120164 RepGUIMeaVacPickUp Reply to GUI: Measure vacuum at
pick-up position
1
1120165 RepGUIMeaComAirPickUp Reply to GUI: Measure compressed
air at pick-up position
1
1120166 RepGUIMeaVacHold Reply to GUI: Measure vacuum in the
holding circuit
1
1120167 RepGUIMeaNozOffset Reply to GUI: Measure nozzle offset 1
1120168 RepGUIReqVacAllNozzle Reply to GUI: Request vacuum for all
nozzle at the revolver
1
1120169 RepGUIReqNozConf Reply to GUI: Request current nozzle
configuration
1
1120170 RepGUIReqReqNozConf Reply to GUI: Request required
nozzle configuration
1
1120171 RepGUISetNozConf Reply to GUI: Set nozzle
configuration state to OK
1
1120172 RepGUIReqNozChaConf Reply to GUI: Request nozzle
changer configuration
1
1120173 RepGUIConNozChaConf Reply to GUI: Confirm nozzle changer
configuration
1
1120174 RepGUISetNozChaRefill Reply to GUI: Set nozzle changer
state to refilled
1
1120175 RepGUIICHeadRefRun Reply to GUI: IC head reference run 1
1120176 RepGUITurnDonIC Reply to GUI: Turn d-axis on IC-head 1
1120177 RepGUIZaxisOn Reply to GUI: Activate z-axis
clamping on IC-head
1
1120178 RepGUIZaxisOff Reply to GUI: Deactivate z-axis
clamping on IC-head
1
1120179 RepGUIComAirOn Reply to GUI: IC-Head Compressed
air ON
1
1120180 RepGUIComAirOff Reply to GUI: IC-Head Compressed
air OFF
1
1120181 RepGUIVacOn Reply to GUI: IC-Head Vacuum ON 1
1120182 RepGUIVacOff Reply to GUI: IC-Head Vacuum OFF 1
1120183 RepGUIStoreNozzle Reply to GUI: Store nozzle in nozzle
changer
1
1120184 RepGUIPickUpNoz Reply to GUI: Pick-up Nozzle 1
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 227 of 252
&(,' 1DPH 'HVFULSWLRQ
1120185 RepGUIMeaVac Reply to GUI: Measure vacuum 1
1120186 RepGUIReqNoz Reply to GUI: Request nozzle on IC-
Head
1
1120187 RepGUINozChaConfIC Reply to GUI: Request nozzle
changer configuration for IC-Head
1
1120188 RepGUIConNozChaConfIC Reply to GUI: Confirm nozzle changer
configuration for IC-Head
1
1120189 RepGUIGanSerPos Reply to GUI: Move gantry to service
position
1
1120190 RepGUIGanWaitPos Reply to GUI: Move gantry to waiting
position
1
1120191 RepGUIGanToZero Reply to GUI: Move gantry to zero
point
1
1120192 RepGUIGanRefRun Gantry reference run 1
1120193 RepGUIPCBtoCenter Reply to GUI: Move PCB in the center
conveyor
1
1120194 RepGUIPCBtoOutput Reply to GUI: Move PCB in the output
conveyor
1
1120195 RepGUIStopper Reply to GUI: Actuate stopper 1
1120196 RepGUILiftingTable Reply to GUI: Actuate lifting table 1
1120197 RepGUITransSlow Reply to GUI: Transport slow 1
1120198 RepGUITransFast Reply to GUI: Transport fast 1
1120199 RepGUITransStop Reply to GUI: Transport stop 1
1120200 RepGUIReqTransState Reply to GUI: Request transport state 1
1120201 RepGUITransWiderSlow Reply to GUI: Transport wider slow 1
1120202 RepGUITransWiderFast Reply to GUI: Transport wider fast 1
1120203 RepGUITransNarSlow Reply to GUI: Transport narrower
slow
1
1120204 RepGUITransNarFast Reply to GUI: Transport narrower fast 1
1120205 RepGUIMeaTransWidth Reply to GUI: Measure transport
width
1
1120206 RepGUIReqTrayWPC Reply to GUI: WPC request tray 1
1120207 GUIRetAllNoz Mesage from GUI: Return all nozzles
to the nozzle changer,
<GUINOZZLETYPE> and
<GUIGANTRYNR> will be updated
1
1120208 GUIPickupAllNoz Mesage from GUI: Pick up all nozzles,
<GUINOZZLETYPE> and
<GUIGANTRYNR> will be updated
1
1120209 GUIThrowAllNoz Mesage from GUI: Throw away all
nozzles, <GUINOZZLETYPE> and
<GUIGANTRYNR> will be updated
1
1120210 GUIReplace1Noz Mesage from GUI: Replace one
nozzle, <GUINOZZLETYPE> and
1
GEM for SIPLACE V5.01
Page 228 of 252 ©Siemens AG, all rights reserved
&(,' 1DPH 'HVFULSWLRQ
<GUIGANTRYNR> will be updated
1120211 RepGUIRetAllNoz Reply to GUI: Return all nozzles to the
nozzle chnager
1
1120212 RepGUIPickupAllNoz Reply to GUI: Pichk up all nozzles 1
1120213 RepGUIThrowAllNoz Reply to GUI: Throw away all nozzles 1
1120214 RepGUIReplace1Noz Reply to GUI: Replace one nozzle 1
1120215 ToGUICompBarcode The component barcode list is
transmitted to the GUI
1
1120216 ToGUICrtlModeChanged Control Mode change (Stand-alone,
GEM-Host or LCU) is completed.
1
1120217 ToGUIVSOpFinished Vision Operation is completed 1
1120218 GUIGetCrtlMode GUI asks for the current Control Mode
(Stand-alone, GEM-Host, LCU)
1
1120219 GUISetCrtlMode GUI transmits the new Control Mode
(OK-Button)
1
1120220 GUIVSSetText A text is inserted in the „vision screen“ 1
1120221 GUIGetFluxPF GUI asks for the package forms,
which should be dipped in flux
1
1120222 GUISetFluxPF GUI transmits the list of package
forms which should be dipped in flux
(OK-Button)
1
1120223 GUIGetFluxPara GUI asks for the current flux
parameters
1
1120224 GUISetFluxPara GUI set flux parameters (OK-Button) 1
1120225 GUISaveVSPicture Current image in the vision system
should be saved on floppy
1
1120226 GUIVSDoEval Start vision evaluation 1
1120227 RepGUIGetCrtlMode Reply to GUI: GUI asks for the current
Control Mode (Stand-alone, GEM-
Host, LCU)
1
1120228 RepGUISetCrtlMode Reply to GUI: GUI transmits the new
Control Mode (OK-Button)
1
1120229 RepGUIVSSetText Reply to GUI: A text is inserted in the
„vision screen“
1
1120230 RepGUIGetFluxPF Reply to GUI: GUI asks for the
package forms, which should be
dipped in flux
1
1120231 RepGUISetFluxPF Reply to GUI: GUI transmits the list of
package forms which should be
dipped in flux (OK-Button)
1
1120232 RepGUIGetFluxPara Reply to GUI: GUI is asking for the
current flux parameters
1
1120233 RepGUISetFluxPara Reply to GUI: GUI set flux parameters
(OK-Button)
1
