GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 229 of 252
&(,' 1DPH 'HVFULSWLRQ
1120234 RepGUISaveVSPicture Reply to GUI: Current image in the
vision system should be saved on
floppy
1
1120235 RepGUIVSDoEval Reply to GUI: Start vision evaluation 1
1120236 ToGUISkip PCB not fully populated
1120237 ToGUIMCready MC Announce
1120238 ToGUISieTestStarted SIETEST was started
1120239 ToGUISieTestFinished SIETEST finished
1120240 GUIReady Meassage „Ready“from GUI
1120241 GUIReturnOneNozzle Return one nozzle to the nozzle
changer, <GUINOZZLETYPE> and
<GUIGANTRYNR> will be updated
1120242 GUIPickUpOneNozzle Pick Up a new nozzle,
<GUINOZZLETYPE> and
<GUIGANTRYNR> will be updated
1120243 GUIRejectOneNozzle Throw away one nozzle,
<GUINOZZLETYPE> and
<GUIGANTRYNR> will be updated
1120244 GUIActuateNozzleChanger Actuate the clamping mechanism of
the nozzle changer
1120245 GUIAckNozzleChange Acknowledge nozzle change
1120246 GUISkipTrack Skip track
1120247 GUIEndSkip End track skipping
1120248 GUIReqSietestStart Request to start the SIETEST
software
1120249 RepGUIReady Reply to GUI: Meassage „Ready“from
GUI
1120250 RepGUIReturnOneNozzle Reply to GUI: Return one nozzle to the
nozzle changer
1120251 RepGUIPickUpOneNozzle Reply to GUI: Pick Up a new nozzle
1120252 RepGUIRejectOneNozzle Reply to GUI: Throw away one nozzle
1120253 RepGUIActuateNozzleCha
nger
Reply to GUI: Actuate the clamping
mechanism of the nozzle changer
1120254 RepGUIAckNozzleChange Reply to GUI: Acknowledge nozzle
change
1120255 RepGUISkipTrack Reply to GUI: Skip track
1120256 RepGUIEndSkip Reply to GUI: End track skipping
1120257 RepGUIReqSietestStart Reply to GUI: Request to start the
SIETEST software
1120258 ToGUIRefRunReady Machine is ready to start reference
run
1
1120259 ToGUInewjobname display new jobname 1
1120260 ToGUItextbox display textbox 1
GEM for SIPLACE V5.01
Page 230 of 252 ©Siemens AG, all rights reserved
&(,' 1DPH 'HVFULSWLRQ
1120261 GUIclearTextVS Clear text in vision screen 1
1120262 GUIrequestTransportState Request transport state 1
1120263 RepGUIclearTextVS Reply to GUI: Clear text in vision
screen
1
1120264 RepGUIrequestTransportSt
ate
Reply to GUI: Request transport state 1
&$1%XV
CEID Name Description
1211001 FM_CAN_INI_APL CAN bus: Initialization faulty* 1
1211002 FM_CAN_SND_OVL CAN bus: transmission source overflow* 1
1211003 FM_CAN_NO_CAR CAN bus: reception job before
transmission job*
1
1211004 FM_CAN_RCV_TOUT CAN bus: reception call aborted with
timeout*
1
1211005 FM_CAN_RCV_OVR CAN bus: reception source overflow* 1
1211006 FM_CAN_CNT_EXL CAN bus: error hysteresis counter
exceeded*
1
1211007 FM_CAN_BUS_OFF CAN bus: switched out* 1
1211008 FM_CAN_FHL_NR_UNBE
KANNT
CAN bus: unknown error number* 1
1211009 FM_CAN_MSG_VAK_SC
HALT_SP
RV: vacuum cannot be switched off* 1
1211010 FM_CAN_MSG_VAK_SC
HALT_IC
IC: vacuum cannot be switched off* 1
1211011 FM_CAN_MSG_BLASLUF
T_SCHALT_SP
RV: forced air cannot be switched off* 1
1211012 FM_CAN_MSG_BLASLUF
T_SCHALT_IC
IC: forced air cannot be switched off* 1
1211013 FM_CAN_MSG_LS_ZHS_
FALSE
Star can't be turned due to light barrier z-
top*
1
1211014 FM_CAN_MSG_SM_DPS
_FALSE
Star can't be turned due to d-axis feed
drive*
1
1211015 FM_CAN_MSG_SM_ZHS_
FALSE
Star can't be turned due to pick-up/place
valve actuator*
1
1211016 FM_CAN_MSG_SM_BAS_
FALSE
Star can't be turned due to ejection valve
actuator*
1
1211017 FM_CAN_MSG_LS_ZHS_
START_XY
RV: Gantry can't be moved due to light
barrier z-top*
1
1211018 FM_CAN_MSG_LS_ZHI_S
TART_XY
IC: Gantry can't be moved due to Bero z-
top*
1
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 231 of 252
CEID Name Description
1211019 FM_CAN_MSG_ZHS_ABH RV: Fault in pick-up/place valve actuator
during pick-up*
1
1211020 FM_CAN_MSG_LS_Z_O_
ABH_SP
RV: Light barrier z-top not triggered
during pick-up*
1
1211021 FM_CAN_MSG_LS_Z_O_
ABH_IC
IC: Bero z-top not triggered during pick-
up*
1
1211022 FM_CAN_MSG_ZHS_BST RV: Fault in pick-up/place valve actuator
during placement*
1
1211023 FM_CAN_MSG_LS_Z_O_
BST_SP
RV: Light barrier z-top not triggered
during placement*
1
1211024 FM_CAN_MSG_LS_Z_O_
BST_IC
IC: Bero z-top not triggered during
placement*
1
Revolver Head 1
CEID Name Description
1310001 Place1Cycle Placement cycle completed on SP-head 1 and
<PLACEINFOREV1> will be updated.
5
1310002 PickUp1Cycle Pick-up cycle completed on SP-head 1 and
<PICKUPINFOREV1> will be updated.
8
1310003 Nozzle1changed <NOZZLECONF1> changed on revolver head 1
(not in single function mode).
14
1310004 RefRunHead1 Head reference run complete on revolver head 1. 1
1310005 NozzleRefRun1 <NOZZLECONF1> length reference run complete
on revolver head 1 and <HEIGHTREV1> will be
updated.
14
1310006 VacRefRun1 <VAKUUMDATAREV1> reference run complete on
revolver head 1.
21
1311007 FM_VAK_SEGM_
UNDICHT_SP
Leak in segment after placement and
<VAKUUMDATAREV1> will be updated. *
21
1311008 FM_GESCHL_VA
K_GRENZE_SP
Vacuum to low with closed valve* 1
Revolver Head 2
CEID Name Description
1410001 Place2Cycle Placement cycle completed on SP-head 2 and
<PLACEINFOREV2> will be updated.
6
1410002 PickUp2Cycle Pick-up cycle completed on SP-head 2 and
<PICKUPINFOREV2> will be updated.
9
1410003 Nozzle2changed <NOZZLECONF2> changed on revolver head 2
(not in single function mode).
15
1410004 RefRunHead2 Head reference run complete on revolver head 2. 1
1410005 NozzleRefRun2 <NOZZLECONF2> length reference run complete
on revolver head 2 and <HEIGHTREV2> will be
15
