GEM for SIPLACE V5.01
Page 230 of 252 ©Siemens AG, all rights reserved
&(,' 1DPH 'HVFULSWLRQ
1120261 GUIclearTextVS Clear text in vision screen 1
1120262 GUIrequestTransportState Request transport state 1
1120263 RepGUIclearTextVS Reply to GUI: Clear text in vision
screen
1
1120264 RepGUIrequestTransportSt
ate
Reply to GUI: Request transport state 1
&$1%XV
CEID Name Description
1211001 FM_CAN_INI_APL CAN bus: Initialization faulty* 1
1211002 FM_CAN_SND_OVL CAN bus: transmission source overflow* 1
1211003 FM_CAN_NO_CAR CAN bus: reception job before
transmission job*
1
1211004 FM_CAN_RCV_TOUT CAN bus: reception call aborted with
timeout*
1
1211005 FM_CAN_RCV_OVR CAN bus: reception source overflow* 1
1211006 FM_CAN_CNT_EXL CAN bus: error hysteresis counter
exceeded*
1
1211007 FM_CAN_BUS_OFF CAN bus: switched out* 1
1211008 FM_CAN_FHL_NR_UNBE
KANNT
CAN bus: unknown error number* 1
1211009 FM_CAN_MSG_VAK_SC
HALT_SP
RV: vacuum cannot be switched off* 1
1211010 FM_CAN_MSG_VAK_SC
HALT_IC
IC: vacuum cannot be switched off* 1
1211011 FM_CAN_MSG_BLASLUF
T_SCHALT_SP
RV: forced air cannot be switched off* 1
1211012 FM_CAN_MSG_BLASLUF
T_SCHALT_IC
IC: forced air cannot be switched off* 1
1211013 FM_CAN_MSG_LS_ZHS_
FALSE
Star can't be turned due to light barrier z-
top*
1
1211014 FM_CAN_MSG_SM_DPS
_FALSE
Star can't be turned due to d-axis feed
drive*
1
1211015 FM_CAN_MSG_SM_ZHS_
FALSE
Star can't be turned due to pick-up/place
valve actuator*
1
1211016 FM_CAN_MSG_SM_BAS_
FALSE
Star can't be turned due to ejection valve
actuator*
1
1211017 FM_CAN_MSG_LS_ZHS_
START_XY
RV: Gantry can't be moved due to light
barrier z-top*
1
1211018 FM_CAN_MSG_LS_ZHI_S
TART_XY
IC: Gantry can't be moved due to Bero z-
top*
1
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 231 of 252
CEID Name Description
1211019 FM_CAN_MSG_ZHS_ABH RV: Fault in pick-up/place valve actuator
during pick-up*
1
1211020 FM_CAN_MSG_LS_Z_O_
ABH_SP
RV: Light barrier z-top not triggered
during pick-up*
1
1211021 FM_CAN_MSG_LS_Z_O_
ABH_IC
IC: Bero z-top not triggered during pick-
up*
1
1211022 FM_CAN_MSG_ZHS_BST RV: Fault in pick-up/place valve actuator
during placement*
1
1211023 FM_CAN_MSG_LS_Z_O_
BST_SP
RV: Light barrier z-top not triggered
during placement*
1
1211024 FM_CAN_MSG_LS_Z_O_
BST_IC
IC: Bero z-top not triggered during
placement*
1
Revolver Head 1
CEID Name Description
1310001 Place1Cycle Placement cycle completed on SP-head 1 and
<PLACEINFOREV1> will be updated.
5
1310002 PickUp1Cycle Pick-up cycle completed on SP-head 1 and
<PICKUPINFOREV1> will be updated.
8
1310003 Nozzle1changed <NOZZLECONF1> changed on revolver head 1
(not in single function mode).
14
1310004 RefRunHead1 Head reference run complete on revolver head 1. 1
1310005 NozzleRefRun1 <NOZZLECONF1> length reference run complete
on revolver head 1 and <HEIGHTREV1> will be
updated.
14
1310006 VacRefRun1 <VAKUUMDATAREV1> reference run complete on
revolver head 1.
21
1311007 FM_VAK_SEGM_
UNDICHT_SP
Leak in segment after placement and
<VAKUUMDATAREV1> will be updated. *
21
1311008 FM_GESCHL_VA
K_GRENZE_SP
Vacuum to low with closed valve* 1
Revolver Head 2
CEID Name Description
1410001 Place2Cycle Placement cycle completed on SP-head 2 and
<PLACEINFOREV2> will be updated.
6
1410002 PickUp2Cycle Pick-up cycle completed on SP-head 2 and
<PICKUPINFOREV2> will be updated.
9
1410003 Nozzle2changed <NOZZLECONF2> changed on revolver head 2
(not in single function mode).
15
1410004 RefRunHead2 Head reference run complete on revolver head 2. 1
1410005 NozzleRefRun2 <NOZZLECONF2> length reference run complete
on revolver head 2 and <HEIGHTREV2> will be
15
GEM for SIPLACE V5.01
Page 232 of 252 ©Siemens AG, all rights reserved
CEID Name Description
updated.
1410006 VacRefRun2 <VAKUUMDATAREV2> reference run complete on
revolver head 2.
22
IC-Head
CEID Name Description
1510001 ICpickUp Component picked up by IC-head and
<PICKUPINFOIC> will be updated.
10
1510002 ICOpCenter Component optically centered by IC-head 1
1510003 ICrejecet Component rejected by IC-head 12
1510004 ICtwist Nozzle on IC-head twisted 1
1510005 ICplace Component placed by IC-head and
<PLACEINFOIC> will be updated.
7
1510006 ICcoplan <COPLANARITYDATAIC> measurement
complete.
12
1510007 ICNozzleRet IC-head <NOZZLERETURN> returned. 16
1510008 ICNozzlePick IC-head <NOZZLECONFIC> picked up. 17
1511009 FM_VAK_SEGM_
UNDICHT_IC
Leak in segment after placement and
<VAKUUMDATAIC> will be updated. *
21
Data Preparation
CEID Name Description
1611000 FM_LRR_QUIT_MK Error during loading fiducials
in MVS*
1
1611001 FM_LRR_DA_NO_KLL DP: Glue type list KLL
incorrectly loaded*
1
1611002 FM_LRR_KVMA_RASTER_KL_ACHS DP: axis type incorrect in
small gantry mapping data*
1
1611003 FM_LRR_KVMA_RASTER_KL_PORTAL DP: Gantry ID error in small
gantry mapping data*
1
1611004 FM_LRR_QUIT_GF_GEO Error while loading GF geom.
description data into MVS*
1
1611005 FM_LRR_QUIT_GF_MES Error while loading GF meas.
conditions data into MVS *
1
1611006 FM_LRR_QUIT_MK_DEL Error during deleting fiducials
in MVS*
1
1611007 FM_LRR_QUIT_MK_ZEN Error while loading fiducial
centering param. into MVS*
1
1611008 FM_LRR_QUIT_GF_CO Error while loading coplanarity
data into module*
1
