GEM for SIPLACE V5.01
Page 232 of 252 ©Siemens AG, all rights reserved
CEID Name Description
updated.
1410006 VacRefRun2 <VAKUUMDATAREV2> reference run complete on
revolver head 2.
22
IC-Head
CEID Name Description
1510001 ICpickUp Component picked up by IC-head and
<PICKUPINFOIC> will be updated.
10
1510002 ICOpCenter Component optically centered by IC-head 1
1510003 ICrejecet Component rejected by IC-head 12
1510004 ICtwist Nozzle on IC-head twisted 1
1510005 ICplace Component placed by IC-head and
<PLACEINFOIC> will be updated.
7
1510006 ICcoplan <COPLANARITYDATAIC> measurement
complete.
12
1510007 ICNozzleRet IC-head <NOZZLERETURN> returned. 16
1510008 ICNozzlePick IC-head <NOZZLECONFIC> picked up. 17
1511009 FM_VAK_SEGM_
UNDICHT_IC
Leak in segment after placement and
<VAKUUMDATAIC> will be updated. *
21
Data Preparation
CEID Name Description
1611000 FM_LRR_QUIT_MK Error during loading fiducials
in MVS*
1
1611001 FM_LRR_DA_NO_KLL DP: Glue type list KLL
incorrectly loaded*
1
1611002 FM_LRR_KVMA_RASTER_KL_ACHS DP: axis type incorrect in
small gantry mapping data*
1
1611003 FM_LRR_KVMA_RASTER_KL_PORTAL DP: Gantry ID error in small
gantry mapping data*
1
1611004 FM_LRR_QUIT_GF_GEO Error while loading GF geom.
description data into MVS*
1
1611005 FM_LRR_QUIT_GF_MES Error while loading GF meas.
conditions data into MVS *
1
1611006 FM_LRR_QUIT_MK_DEL Error during deleting fiducials
in MVS*
1
1611007 FM_LRR_QUIT_MK_ZEN Error while loading fiducial
centering param. into MVS*
1
1611008 FM_LRR_QUIT_GF_CO Error while loading coplanarity
data into module*
1
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 233 of 252
CEID Name Description
1611009 FM_LRR_QUIT_PP Error while loading parameter
pool into MVS*
1
1611010 FM_LRR_DA_ALLGEMEIN Data preparation : internal
error*
1
1611011 FM_LRR_DA_STRG Data preparation : run error* 1
1611012 FM_LRR_DA_MA_AKT_NOK Data preparation : cannot
save current MA data*
1
1611013 FM_LRR_DA_LOOK DP: required equipment
unknown*
1
1611014 FM_LRR_DA_SVC DP: incorrect operating
system call*
1
1611015 FM_LRR_DA_LRKOM_OHNE_LR DP: No LC command in
service without LC*
1
1611016 FM_LRR_DA_DVS_LRSD DP: Set-up without valid
machine data*
1
1611017 FM_LRR_DA_DVS_LNUD DP: Cluster without valid set-
up data*
1
1611018 FM_LRR_DA_DVS_LGFD DP: Package form without
valid set-up data*
1
1611019 FM_LRR_DA_DVS_LGFE DP: Delete package form
without valid set-up data*
1
1611020 FM_LRR_DA_DVS_LADEN DP: Set-up and cluster without
valid machine data*
1
1611021 FM_LRR_DA_DV_STUFE DP: Error in data supply from
LC*
1
1611022 FM_LRR_DA_REQ_OHNE_VS DP: invalid request received
from visiontask*
1
1611023 FM_LRR_FILE_DISMT DP: cannot log off drive* 1
1611024 FM_LRR_TL_PROLOG DP: Head in local files wrong
or incomplete*
1
1611025 FM_LRR_QUITTUNG_NEG DP: Loading of pack. form or
fid. data not successful*
1
1611026 FM_LRR_DA_PMS DP: Error in list for passpoint
sets*
1
1611027 FM_LRR_DA_MA Data preparation : error in
machine data*
1
1611028 FM_LRR_KVMA_ABSTANDSHALTER MA data: unknown spacer
type*
1
1611029 FM_LRR_KVMA_MKRANGE MA data: invalid fiducial
number for system fiducial*
1
1611039 FM_LRR_KVMA_NO_KAMERA MA data: Error in sensor
system types*
1
1611040 FM_LRR_KVMA_HOFF MA data: missing height
offset*
1
1611041 FM_LRR_KVMA_KAMERAV MA data: too many zero point 1
GEM for SIPLACE V5.01
Page 234 of 252 ©Siemens AG, all rights reserved
CEID Name Description
fiducials*
1611042 FM_LRR_KVMA_RASTER MA data: Mapping plate
irregular*
1
1611043 FM_LRR_KVMA_PIPART MA data: Error in nozzle
type/vacuum correction
values*
1
1611044 FM_LRR_KVMA_PIPW MA data: invalid compartment
at nozzle changer*
1
1611045 FM_LRR_KVMA_UNKNOWN_PIPW MA data: unknown nozzle
changer*
1
1611046 FM_LRR_DA_NU Data preparation : error in
cluster data*
1
1611047 FM_LRR_KVNU_NO_PIPART Clust data: Error in nozzle
type/vac. correct'n values*
1
1611048 FM_LRR_KVNU_NO_KETTV Clust. data: Error in chain of
placement positions*
1
1611049 FM_LRR_KVNU_NO_PSATZ Clust. data: Error in passpoint
sets*
1
1611050 FM_LRR_KVNU_SPURNUM Clust. data: incorrect track
number*
1
1611051 FM_LRR_KVNU_NO_PS_MKL Clust. data: Error during
creation of fiducial list*
1
1611052 FM_LRR_KVNU_ESBE_V_OVL Clust. data: Number fiducials
or passpoint to large*
1
1611053 FM_LRR_KVNU_ES_OFS_NULL Clust. data: invalid X/Y offset
0 in indiv. circuit*
1
1611054 FM_LRR_KVNU_NO_STELLPL Clust. data: invalid location for
machine type*
1
1611055 FM_LRR_KVNU_OVL Clust. data: incorrect
reference in placement
options*
1
1611056 FM_LRR_DA_RS Data preparation : error in set-
up data*
1
1611057 FM_LRR_KVRS_SPURKONV Set-up data: Error during
conversion of tracks*
1
1611058 FM_LRR_KVRS_NO_SPURV Set-up data: missing track
chain*
1
1611059 FM_LRR_KVRS_STELLPL Set-up data: invalid location
for machine type*
1
1611060 FM_LRR_KVRS_NO_SST Set-up data: unknown sensor
system type*
1
1611061 FM_LRR_KVRS_OVL Set-up data: invalid reference
in set-up message*
1
1611062 FM_LRR_KVRS_UNKNOWN_PIPW Set-up data: unknown nozzle
changer type*
1
1611063 FM_LRR_KVRS_UNKNOWN_ART Set-up data: unknow track 1
