GEM for SIPLACE V5.01

CEID Name Description

stopped*

1611114 FM_LRR_EM_UNDEF LRR: Undefined operation

with and without LC*

1611115 FM_LRR_EM_UNKNOWN LRR: Undefined error in LC

reception*

1611116 FM_LRR_EM_MEM LRR: No memory available* 1

1611117 FM_LRR_EM_INTP LRR: Defective or incomplete

message from LC*

1611118 FM_LRR_EM_IEC LRR: Error during data

transm. via IEC bus (LISTEN)

1611119 FM_LRR_EM_SVC LRR: Error during system call* 1

1611120 FM_SRLR_LA_DT_GRENZE DP: Data limits exeeded * 1

1611121 FM_LRR_GK_QUITTUNG_NEG Neg. acknowl. from GC, data

preparation cannot continue*

1611122 FM_LRR_GEM DP cannot correctly create

GEM data structures*

1611123 FM_LRR_GEM_FILE DP for GEM: Error upon

writing a file for storing GEM

data*

1611124 FM_HDA_UNKNOWN_ORDER HDP: Unknown command

from Mailbox*

1611125 FM_HDA_BUFFER HDP: Error upon accessing

internal buffer*

1611126 FM_HDA_MAKE_AKTUELL_HST HDP: Process program file for

MC cannot be created*

1611127 FM_HDA_MAKE_AKTUELL_DAT HDP: Copy of MC structures

cannot be created*

1611128 FM_HDA_AKTUELL_HST_HEADER HDP: Faulty header of

process program file*

1611129 FM_HDA_AKTUELL_HST_ALL HDP: Faulty process program

file*

1611130 FM_HDA_INAKTIV HDP: Inactive host data

preparation*

1611131 FM_HDA_PARSE HDP: Faulty placement

program*

1611132 FM_HDA_AKTUELL_DAT_READ HDP: Copy of MC data

structures cannot be sent to

GEM*

1611133 FM_HDA_GF_DATEI HDP: GF file cannot be read* 1

1611134 FM_HDA_MK_DATEI HDP: MK file cannot be read* 1

1611135 FM_MK_FELDGRENZE Field boundaries in fiducial

data were exceeded*

GEM for SIPLACE V5.01

* Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these CAN-bus

collection events.

7UROOH\

CEID Name Description

1711001 FM_WAG_CODE_ERROR Check sum error in table program* 1

1711002 FM_WAG_UNBEK_TELE Unknown message to table* 1

1711003 FM_WAG_BE_ENTSORG_70 Caution: Filling level of rejected.

components receptacle 70%*

1711004 FM_WAG_BE_ENTSORG_VOLL Receptacle of rejected components

full*

1711005 FM_WAG_F_KOMM_UNTERBR Communication table-feeder

interrupted*

1711006 FM_WAG_F_KOMM_NOK Communication table-feeder

disturbed*

1711007 FM_WAG_47 Undefined error number of

component table (code 47) *

1711008 FM_WAG_48 Undefined error number of

component table (code 48) *

1711009 FM_WAG_49 Undefined error number of

component table (code 49) *

1711010 FM_WAG_50 Feeder rail of bulk case feeder not

installed*

1711011 FM_WAG_F_ABLAUF_NOK Software-Operation in feeder

disturbed*

1711012 FM_WAG_F_FOL_GERISSEN Foil torn* 1

1711013 FM_WAG_F_FOL_NICHT_AB Foil not removed* 1

1711014 FM_WAG_F_TRANSPORT_NOK Transport in feeder disturbed* 1

1711015 FM_WAG_F_GURTENDE Caution: Belt end* 1

* Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these trolley

collection events.

0LVFHOODQHRXV

CEID Name Description

2010001 CoverOpen The protective covers was opened 1

2010002 CoverClosed The protective covers was closed 1

2010003 PCBready Placement is finished for the PCB in the

center conveyor. The PCB will now be

transported to the output conveyor.

<GANTRYINFOREV1> and

GEM for SIPLACE V5.01

<GANTRYINFOREV2> or

<GANTRYINFOIC> will be updated.

2010004 TrackFull Track reset to full 1

2010005 TrackEmpty Track set to empty 1

2010006 RefRunGantry1 Reference run complete for the gantry 1

axis

2010007 RefRunGantry2 Reference run complete for the gantry 2

axis

2010008 TableDownload Software downloaded to the table and

<SOFTWAREREVTABLE> will be

updated.

2010009 SingleCircuitOmit The machine signals that it found a single

circuit to omit (Ink Punkt)

2010010 TapeCutLeft Tape cut on left side of machine 1

2010011 TapeCutRight Tape cut on right side of machine 1

2010013 PCBstartProcessing Start of the placement process for the

PCB in the center conveyor

2010015 MachineReStarted SIPLACE station is re-booting 1

2010016 PickupError An Pickup-Error has occured and

<SEGMENT>, <COMPONENTNAME>,

<MASCHINESIDE>, <TRACKNUMBER>,

<DIVISION>, <LEVEL>, <GANTRYID>,

will be updated

2010017 PlaceError An Place-Error has occured and

<SEGMENT>,

<REFERENCEDESIGNATOR>,

<COMPONENTNAME>, <GANTRYID>,

<GANTRYGROUPID>, <HEADID>,

<PACKAGEFORMNUMBER> and

<PLACEERRORDESCRIPTION> will be

updated

)OX[

CEID Name Description

2111001 FM_FLUX_SYSFEHL Flux module: System error in SW

module*

2111002 FM_FLUX_WRITE_FLUXMA Flux module: Error writing FLUX.MA file* 1

2111003 FM_FLUX_READ_FLUXMA Flux module: Error reading FLUX.MA file* 1

2111004 FM_FLUX_NOT_INIT Flux pump not initialized* 1

2111005 FM_FLUX_INITIALISIEREN Error upon initialization of flux pump* 1

2111006 FM_FLUX_VALVE Faulty flux valve* 1

2111007 FM_FLUX_PLUNGER Faulty flux syringe* 1

2111008 FM_FLUX_TIMEOUT Timeout of flux pump* 1

2111009 FM_FLUX_COMMAND Incorrect command to flux pump* 1
