GEM for SIPLACE V5.01

2111010 FM_FLUX_CHECKSUMME Checksum error upon activation of flux

pump*

2111011 FM_FLUX_Z_OBEN Z-axis of flux nozzle not in raised

position*

2111012 FM_FLUX_Z_KLEMMT Z-axis of flux nozzle jammed* 1

2111013 FM_FLUX_LEER Flux tank empty* 1

2111014 FM_FLUX_NACHFUELLEN Warning: Replenish flux tank* 1

* Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these flux

collection events.

GEM for SIPLACE V5.01

 $ODUPV

There are no alarms defined for SIPLACE

$/,' $/&' $/7; 'HVFULSWLRQ 21&(,' 2))

&(,'

$/,' Alarm ID

$/&' Alarm Severity Code. The low-order 7-bits of ALCD specifies the severity

code. The high-order bit (bit-8) shows the current alarm state (1=SET,

0=CLEAR).

$/7; Alarm Text. This is the actual string sent the Host in the Alarm Report

(S5F1).

21&(,' This is the Collection Event that is signaled when the alarm state changes

from CLEAR to SET ("going-on").

2))&(,' This is the Collection Event that is signaled when the alarm state changes

from SET WRCLEAR ("going-off").
