 6,3/$&(3URFHVV6WDWH7UDQVLWLRQV

# From Trigger To Description

1 Unknown Power-Up Machine

Initialization

At power-up, the Equipment

defaults to the 0DFKLQH

LQLWLDOL]DWLRQ state.

2 Machine

Initialization

Machine is

ready

Processing All data is available to

produce a board. All

peripheral equipment like

the Vision system is

initialized and the machine

has finished the reference

runs correctly. In this state

the machine will start its

work, when a PCB is put on

the input conveyor

3 Processing new Data form

the Host

Machine

Initialization

New production data is

send during the machine is

processing a board. The

board will be finished and

the machine will go to the

0DFKLQHLQLWLDOL]DWLRQ state

4 Machine

Initialization

a) Fatal Error

during machine

initialization

b) Stop-Button

on GUI

Single

Function

When a fatal error occurs

during machine initialization

it will automatically switch to

VLQJOHIXQFWLRQ mode.

In the case that the

operator press the Stop-

Button on the GUI, the

machine will first end the

board in the center

conveyor (if there is one)

and will then enter the

VLQJOHIXQFWLRQ mode.

5 Single

Function

Start-Button on

GUI

Machine

Initialization

When the machine is in

single function mode, the

operator press the Start-

button and the Prestate

was machine Initialization

the machine will return to

the 0DFKLQHLQLWLDOL]DWLRQ

state.

6 Processing a) Fatal Error

during machine

initialization

b) Stop-Button

on GUI

Single

Function

When a fatal error occurs

during processing the

machine will automatically

switch to VLQJOHIXQFWLRQ

mode.

In the case that the

operator press the Stop-

Button on the GUI, the

machine will first end the

board in the center

conveyor (if there is one)

and will then enter the

VLQJOHIXQFWLRQ mode.

GEM for SIPLACE V5.01

# From Trigger To Description

7 Single

Function

Start-Button on

GUI

Processing When the machine is in

single function mode, the

operator press the Start-

button and the Prestate

was Processing the

machine will return to the

3URFHVVLQJ state.

 6,3/$&(3URFHVV6WDWHV

0DFKLQH,QLWLDOL]DWLRQ

In this state, the peripheral equipment is initialized and the machine process the

necessary reference runs. The data which was downloaded from the host is split in pieces

for the different subsystem of the machine

3URFHVVLQJ

In this state, the SIPLACE is producing a board.

6LQJOHIXQFWLRQ

In this state, the Operator can teach fiducials, react on run-time-errors like empty feeders.

 5HODWHG9DULDEOHV

The following table lists the variables (SV's, EC's, or DVVALS) which are relevant to the

Equipment processing states. For a more complete description of these variables, see

"Chapter 6 Variables".

Variable Name VID

PREVIOUSPROCESSSTATE 1002012

PROCESSSTATE 1002011

 5HODWHG&ROOHFWLRQ(YHQWV

The following lists the collection events (CEIDs) which are relevant to the Process State.

For a more complete description of these events, see "Appendix B -- Collection Events" or

the description in this chapter.

Collection Event CEID

Init2Process 1000010

Process2Init 1000011

Process2SingleFunction 1000012

SingleFunction2Process 1000013

Init2SingleFunction 1000016

FunctionSingle2Init 1000017

GEM for SIPLACE V5.01

 'DWD&ROOHFWLRQ

 9DULDEOHV

The SIPLACE has a fixed set of Variables which can be read by the Host. Each Variable

is identified by a unique Variable ID (VID). The Variables which exist are shown in

"Appendix A -- Variables".

There are three types of Variables: Status Variables, Data Variables, and Equipment

Constants. The Host can read Variables of any type, but can set values only for

Equipment Constants. The Host can read values for Status Variables and Equipment

Constant whenever the SIPLACE is On-Line, but values for Data Variables are typically

meaningful only immediately after certain Collection Events (CEIDs), and so are typically

reported only in Event Reports (S6F11).

 $UH<RX7KHUH

The Host can send S1F1 at any time to determine if the SECS link is operational. The

SIPLACE responds with S1F2, if the equipment is in the ONLINE & COMMUNICATING

states. This indicates Model Number (MDLN) and Software Revision Number

(SOFTREV).

 +RVW5HTXHVWV6WDWXV

The Host can send S1F3 when the Equipment is On-Line to read Equipment Constants

from the SIPLACE.

The Host can send S2F13 when the Equipment is On-Line to read Equipment Constants

from the SIPLACE.

For this Equipment, S1F3 and S2F13 with a list of VIDs are essentially the same. That is,

either message can return Variables of any type. However, S1F3 with a zero-length list

will return only VIDs of type SV, and S2F13 with a zero-length list will return only VIDs of

type EC.

 6HWWLQJ(TXLSPHQW&RQVWDQWV

The Equipment Operator can change the value for Equipment Constants. Once the

Operator has changed an EC value, the Equipment will note the EqConstChange Event

(CEID 1000001). The VID for the changed EC will be reported to the Host in the variable

ECIDCHANGE (VID 1002036).

 (YHQW5HSRUWV

The SIPLACE has a fixed set of Events which can occur. Each Event is identified by a

unique Collection Event ID (CEID). The CEIDs which exist are shown in "Appendix B --

Collection Events".

When an Event occurs, the Equipment sends the appropriate S6F11 Event Report

message to the Host (if that particular event has been enabled). Event Reports are

defined by the Host (S2F33) and linked to a specific CEID (S2F35).

The Equipment allows the Host to enable and disable Event Reports using S2F37. If the

Host enables a CEID, for which no Event Report is defined, the Equipment will send a

"null" (no data) report when the event occurs.

The Host can "force" Event Reports on the Equipment using the following Event Report

Request messages:

S6F15 Host Requests an Event Report associated with a CEID.

S6F17 Host requests an Annotated Event Report associated with a CEID.

S6F19 Host requests an Event Report associated with a Report ID.
