3 T asks related to maintenance
NPM-TT2 EJM1EE-MB-02M-01
2-1-7-3
3 Tasks related to
maintenance
NPM-TT2 EJM1EE-MB-03M-02
Components of grease gun
The grease gun kit consists of the following 3 pieces.
●Make sure that the nozzle is securely fixed.
●Select a tube nozzle, nozzle that matches the greasing point.
Adjust the nozzle tip if the clamping force is too strong.
Hold hexagonal part with a
spanner wrench
Turn the tip with pliers
1
2
How to adjust the grease gun
3-1-1
Maintenance
3-1
Greasing 1
Nozzle
Grease canister
Grease gun
Cartridge (200g)
Tube nozzle
Cap
Tighten
Loosen
Tip section
Hexagonal
section
