N7201A653E - 第112页
NPM-TT2 EJM1EE-MB-03M-0 2 3-3 -3 Attaching the feeder table cover 2 9 Maintenance 3-3 Detac hing and a ttaching the f eeder table co v er 2 Safety switch Make sure the key of feeder table cover is inserted into the safet…
NPM-TT2 EJM1EE-MB-03M-02
3-3-2
Periodic
inspection
Attaching the feeder table cover 1
Place the feeder table cover
To
6
OFF
SERVO
1
3
2
Push the X-axis
inward
5
Allen
wrench
(3 mm)
Feeder table cover
Left side
Right side
Secure the feeder table cover
(One on either side)
4
Guide
NPM-TT2 EJM1EE-MB-03M-02
3-3-3
Attaching the feeder table cover 2
9
Maintenance
3-3
Detaching and attaching
the feeder table cover 2
Safety switch
Make sure the key of feeder
table cover is inserted into the
safety switch
Check fitting of the safety switch of the
feeder table cover
SERVO
ON
8
7
6
Attach the tray
feeder or the
feeder cart
●For a tray feeder
(→ P.14-8)
●For a feeder cart
(→ P.3-2)
4 Periodic inspection
Every-24-hours
