NPM- TT2 EJM1EE-CT-01 M-02 S-13 4 P eriodic inspection Ev er y-24- hour s 5 P eriodic inspection Ev er y-140- hour s -1 Cleaning the touchscreen -2 Cleaning the nozzle holder (3-nozzle head: option) -3 Cleaning the PCB-s…
NPM-TT2 EJM1EE-CT-01M-02
S-12
2
Overview
-1
Overview
-1-1
Maintenance overview
-1-2
Periodic inspection items by cycle
-1-3
Periodic inspection items by unit
-1-4
Periodic inspection items by applying grease
-1-5
Consumable parts
-1-6
Periodic inspection points by unit
-1-7
Component exchange due to limited-life
3
Tasks
related to
maintenance
-1
Greasing
-2
How to handle the feeder cart
(feeder cart (option))
-3
Detaching and attaching the
feeder table cover
NPM-TT2 EJM1EE-CT-01M-02
S-13
4
Periodic
inspection
Every-24-
hours
5
Periodic
inspection
Every-140-
hours
-1
Cleaning the touchscreen
-2
Cleaning the nozzle holder
(3-nozzle head: option)
-3
Cleaning the PCB-support
blocks
-3-1
Cleaning the PCB-support blocks
(PC size conveyor)
-3-2
Cleaning the PCB-support blocks
(M size conveyor(option))
-4
Cleaning the cover glass
(multi-recognition camera))
-5
Cleaning the feeder table
(13-slot feeder, Feeder cart(option))
-6
Cleaning the table surface
(tray feeder drawer (option))
-7
Checking the connector
(13-slot feeder, Feeder cart(option))
-1
Before operation
-1-1
Inspecting the pressure gauge
-2
After operation
-2-1
Cleaning the components-
ejection box
-2-2
Cleaning the used-tape box
(13-slot feeder, Feeder cart
(option))
-2-3
Cleaning the refuse box
(tray feeder: option)
-3
As needed
-3-1
Cleaning and inspecting the pallet
(fray feeder pallet: option)
NPM-TT2 EJM1EE-CT-01M-02
S-14
6
Periodic
inspection
Every-560-
hours
-1
Greasing the PCB conveyor
-2
Greasing the XY-axis linear
guide
-3
Greasing the nozzle holder
(8-nozzle head (option))
-4
Cleaning the nozzle (option) and
the nozzle changer
(option)
-5
Inspecting the PCB/extension
conveyor
(option)
-6
Cleaning the large reflector
(3-nozzle head (option))
-7
Cleaning the vacuum pump filter
-8
Inspecting the safety switches
-9
Cleaning the PCB detection
sensors
-10
Inspecting the vacuum air path
(Placement head (option))
-11
Inspecting the θ-axis belt
(8-nozzle head (option))
-12
Cleaning the components-
ejection conveyor
(option)
-13
Greasing to the tray feeder
(option)
-14
Cleaning the slot
(tray feeder magazine (option))
-15
Cleaning the safety cover
-16
Inspecting the air drain
(regulator unit)
-17
Greasing the cutting unit
-18
Cleaning the nozzle (option) and
nozzle changer
(option) for
support pins
-19
Cleaning the light-emitting and
light-receiving sections
(height sensor (option))
-20
Cleaning the XY-axis cable
bearer
