EJM1EJ-MB-06 M-02 NPM- TT2 9 11 10 18 Select X-axis 19 Select Y -axis 21 Gr easing the XY -axis linear guide 3 6-2 -5 Maintenance 6-2 22 Wipe off the grease that ran out of the edging ● See steps and . ● Check linear gui…
EJM1EJ-MB-06M-02NPM-TT2
6-2-4
7
Wipe any excess grease off
●Wipe any excess grease off from X-and Y-axis linear guides or adhered grease out of travel
surfaces.
Grease squeezed out
Y-axis linear guide
●Visually check the installation hole on the linear guide rail from the opposite axis and if grease is
contaminated, wipe it off.
Installation hole in the
linear-guide rail
Grease squeezed out Excess grease
X-axis linear guide
8
Check the grease sumps
●Wipe off any grease squeezed out.
Grease sump under Y-axis
(left)
To
9
Grease sump under Y-axis
(right)
Grease sump under X-axis
Every
560
hours
PeriodicPeriodicPeriodicPeriodic
inspection
EJM1EJ-MB-06M-02NPM-TT2
9
11
10
18
Select X-axis
19
Select Y-axis
21
Greasing the XY-axis
linear guide 3
6-2-5
Maintenance
6-2
22
Wipe off the grease that ran out of the edging
●See steps and .
●Check linear guide rail edge and grease nipples whether any
liquefied grease is adhered; if any has, wipe on a regular basis.
7
8
Detach the tray
feeder or the
feeder cart
●For a tray feeder
(→ P.14-8)
●For a feeder cart
(→ P.3-2)
Attach the tray
feeder or the
feeder cart
●For a tray feeder
(→ P.14-8)
●For a feeder cart
(→ P.3-2)
ACTIVATION
20
10 shuttle
EJM1EJ-MB-06M-02NPM-TT2
6-2-6
ACTIVATION
16
10 shuttle
Select Y-axis
17
Select a table
12
13
Select a table
Select X-axis
25
Attach the tray
feeder or the
feeder cart
●For a tray feeder
(→ P.14-8)
●For a feeder cart
(→ P.3-2)
Every
560
hours
PeriodicPeriodicPeriodicPeriodic
inspection
15
14
23
●Repeat steps
to three times
9
22
24
Remove the lint
free cloth
