1 1 Confirmation
NPM-TT2 EJM1EE-CT-01M-02
S-18
17
-1
Switch process
-2
Preparation of switch
-2-1
Power ON/OFF
-2-2
Pushing the X-axis
-2-3
Attach and detach method of feeder table
cover
-2-4
Attach and detach method of grommet
-3
Name and layout
-3-1
Parts layout installed to the feeder cart
-3-2
Parts layout when the single tray feeder is
used
-3-3
Parts layout when the 17-slot feeder cart
is used
-4
Switch from the single tray
feeder to the 17-slot feeder cart
-5
Switch from the 17-slot feeder
cart to the single tray feeder
Appendix
1
1 Confirmation
NPM-TT2 EJM1EE-SF-01N-05
Safety precautions 1
DANGER
Indicates an imminently hazardous situation that could
result in death, severe bodily injury or major property
damage.
WARNING
Indicates a potentially hazardous situation that could result
in death, severe bodily injury or property damage.
CAUTION
Indicates a potentially hazardous situation that could result
in minor or moderate injury and property damage.
Indicates actions that must not be carried out.
Indicates actions that must be carried out.
Indicates matters to which attention must be paid.
Indicates that you must read the manual.
1-1
1-1-1
The degree of danger or injury resulting from incorrect usage are classified and described as follows.
Precautions that must be observed in order to prevent injury to the user or other persons, and damage to
property are described below.
Precautions that must be observed are classified by the symbols shown and described below.
(The followings are examples of symbols)
