NPM- TT2 EJ M1EE-MB-07M-0 2 5 Cleanthenozzleholder Nozzleholder ● Wipeitclean afewtimesand thenleaveittodry. NOTICE ● Donotwipethenozzleholdertip ( filter)and thespringforh olding clampclaws,…

100%1 / 502
NPM-TT2 EJM1EE-MB-07M-02
To
5
4
Pullthenozzleout
NozzleholderNozzle
●Pullitstraightout.Ifpulledoutatan
angle,theclampclawscouldbe
damaged.
NOTICE
3
Detachthenozzleholder
●Turnthenozzleclockwiseasviewedfrombelowwhilepushing
upit.
●Becarefulnottoletthenozzlecushionusespringpopout.
●Thespringforholdingclampclawscanbeeasilydeformedso
youshouldavoidpressingittightlywithyour fingers.
●Remove the all nozzle holders on the placement head in
the same manner.
■Withnozzlesattached
●Usethenozzleholdershaftcleaningtool(option).
●Adjust the groove for 8-nozzle on the cleaning tool to
the positioning pin of the nozzle holder.
●Turnthenozzleclockwiseasviewedfrombelowwhile
pushingupthecleaningtool.
■Withoutnozzlesattached
Positioningpin
Cleaningtool
Groove
5
To
PeriodicPeriodicPeriodic
inspection
●Movetheheadtothepositionwhereyour
workabilityenhances.
Every
1000
hours
7-1-4
NPM-TT2 EJM1EE-MB-07M-02
5
Cleanthenozzleholder
Nozzleholder
●Wipeitcleanafewtimesand
thenleaveittodry.
NOTICE
●Donotwipethenozzleholdertip(filter)andthespringforholding
clampclaws,withacottonswab.
Cleaning the nozzle holder
Cleaning the nozzle holder 3
(8-nozzle head (option))
Maintenance
7-1
Springforholding
clampclaws
Tipofnozzleholder
(filter)
A
B
●CleanonlythepartsAandB(theholeareaofthenozzleholder).
Otherwise,thefiltermaygetcloggedwithdust,orwipingoff
greasecancausethespringtogetrusted.
6
Cleanthetaperface
andtheclampclaw
tip
Model Model No. Remarks
BB-001 : for 8-nozzle head
BB-001 : N510058057AA
BB-001: 5 000 pieces
You can also purchase
these items from;
Sanyo Co., Ltd.
Phone number: +81-721-
24-3376
P753S-A : for 8-nozzle head
P753S-A : N510058942AA P753S-A : 100 pieces
Usethefollowingindustrialswabsforprecisionmachineforcleaning.
NOTICE
7-1-5
Cleaning solvent-
dampened baby cotton
swab
Cleaning solvent-dampened
baby cotton swab
NPM-TT2 EJM1EE-MB-07M-02
FilterNo.:N610097899AA
To
10
9
Cleanthespringforthenozzlecushionuse
Springfornozzlecushion
Driedlintfreecloth
PeriodicPeriodicPeriodic
inspection
Replacethefilter
Flathead
screwdriver
1
2
Nozzleholdertip (filter)
●Removethefilteratthenozzleholdertipwithaflatheadscrewdriver.
●Becarefulnottoforgettotightenthescrewwheninstallingthefilter.
NOTICE
■Ifduststillsettles
7
Keepanairblowgun1.5cmawayfromthenozzle
holderandblowairforabout10seconds(Air
pressureat0.5 MPa)
Nozzle
(fitsurfaceandclampclawtip)
8
Wipetheouter
part
Driedlintfreecloth
1.5cm
●Blowairinthe
directionofthearrow.
●Replacethespringifdeformed.Otherwise,Itmaycauseasliding
problemwiththenozzleholder,therebyleadingtoapickupor
placementerror.Moreover,itmaycausethenozzleholdertobeunable
tobedismountedfromtheheadsothatyouneedtodisassemblethe
headtodismountit.
●Pushthespringintothenozzleholderasdeepaspossible.Also,be
carefulnottoloseitduringmaintenancework.
Every
1000
hours
7-1-6
