8 Periodic inspection Every-3000-hours
NPM-TT2 EJM1EE-MB-07M-02
7-1-13
8 Periodic inspection
Every-3000-hours
NPM-TT2 EJM1EE-MB-08M-01
8-1-1
Tool used: Phillips screwdriver (No.2) and vacuum cleaner Time required: 20 minutes
Cleaning the filter
(main controller)
Maintenance
8-1
Detach the tray
feeder or the
feeder cart on the
rear side
●For a tray feeder
(→ P.14-8)
●For a feeder cart
(→ P.3-2)
1
4
2
OFF
6
Attach the filter
●Put the filter between the springs.
●Hold the handle of the spring and push it
all the way into until the projection A is hooked.
5
Remove dust
attached to
the filter
Spring
Filter
Handle
7
Attach the
cover
● Five screws
8
(Front side)
ON
Unlock the
machine and
Cover
9
Attach the tray
feeder or the
feeder cart on the
rear side
●For a tray feeder
(→ P.14-8)
●For a feeder cart
(→ P.3-2)
Turn OFF the
power and lock
the machine
●Remove the filter, and clear
dust from the filter with a
vacuum cleaner.
