12 Consumable parts replacement
NPM-TT2 EJM1EE-MB-11M-02
11-2-2-5
19
(Returns to the lane switch screen)
18
Mode
switch
Confirming switch 3
For specification for feeder cart(s) on either the front or rear, or on both the front and rear
Maintenance
11-2-2
19
18
17
+
(The PCB-support block goes down
until origin)
Confirm the message
17
12 Consumable parts
replacement
NPM-TT2 EJM1EE-MB-12M-04
Replacing the transfer belt of
the PCB transfer conveyor 1
Describes the procedure for replacing the transfer belt of the PCB transfer conveyor system on the front of the
machine.
Tool used: Allen wrench (2 mm) Time required: 30 to 60 minutes
Maintenance
12-1
12-1-1
1
2
Set the conveyor
width to 150 mm
(To improve
workability)
Detach the tray
feeder or the
feeder cart
●For a tray feeder
(→ P.14-8)
●For a feeder cart
(→ P.3-2)
3
OFF
Turn OFF the
power and lock
the machine
4
5
Push the X-axis
inward
(→[ Operating
Procedure] P. 2-5-4)
6
●Two
Screws:
M4
Remove the
feeder table
cover (→P.3-3)
