NPM- TT2 EJM1EE-MB -12M-04 12-3 -12 10 Attach the UPS battery ② Secure it with six screws. 11 ① Plug the connector Connector 12 Attach the battery cover ● Screws (2) Battery cover Secure with screws. 16 17 ● Screws (3) P…
NPM-TT2 EJM1EE-MB-12M-04
12-3-11
●Screws (6)
9
Bracket Bracket
13
14
15
Attach the cover
●Replacement battery :N510069573AA
Replacing the
batteries 6
Maintenance
12-3
Replacing the UPS battery of the FA computer (LNB) 2
●Screws (3)
Center bracket
Attach the center bracket
Attach the front
cover
Front cover
●Put two claws into the
bottom side and fit the
other two claws into the
upper side of the cover.
After that, push the whole
cover to install it.
Rear side of
FA computer
Remove two brackets from the old UPS battery and install then to the
new one
NPM-TT2 EJM1EE-MB-12M-04
12-3-12
10
Attach the UPS battery
②Secure it with six screws.
11
①Plug the connector
Connector
12
Attach the
battery cover
●Screws (2)
Battery cover
Secure with
screws.
16
17
●Screws (3)
Plug the connector of the UPS battery
Wire
sticker
Front side of
FA computer
Rear side of
FA computer
●Affix the label supplied with
the battery and enter the
date for the next
replacement (current
replacement date + 6 years).
Enter the date for
replacement of
the UPS battery
Replacement
date label
Consumable parts
replacement
①Slide the UPS battery toward you and
install.
Earth strap
●The rear left screw
viewed from the
machine front is
tightened together
with the earth strap.
②Fix the cable with wire
sticker
NPM-TT2 EJM1EE-MB-12M-04
12-4-1
Replacing the air filter
element of the placement
head (Light weight 8-nozzle head) 1
Maintenance
12-4
3
1
ACTIVATION
2
7
8
9
1
2
LeverJoint
This section describes how to replace an air filter element of the placement head (Light weight 8-nozzle head).
Tool used: None Time required: 15 minutes (per head) Lifetime (reference): 6,000 [h]
Replace the air filter element
●Handle the air filter element
with care when replacing
it.(→P.12-4
-3)
Air filter element
Joint
O-ring
●Air filter element
Part No.: N510059928AA
●Check the O-ring for any
deterioration.
If deteriorated, replace it with
a new one.
●O-ring
Part No.: N510059867AA
Press the lever
and insert the
joint with the air
filter element
●8 locations
●Be careful not to drop the
air filter element.
●Do not hold the head
camera and perform
maintenance.
OFF
SERVO
Detach the tray
feeder or the
feeder cart
●For a tray feeder
(→ P.14-8)
●For a feeder cart
(→ P.3-2)
