NPM- TT2 EJ M1EE-MB-13M-0 2 12 Confirm that it has been successfully completed ● If it has been successfully completed, the displa y of each nozzle position is changed from '-' to 'OK'. (The head move…
NPM-TT2 EJM1EE-MB-13M-02
5
6
Open the safety cover
Prepare for height
measurement
7
Install nozzles to the nozzle
positions selected in step
8
3
10
Close the safety cover
9
11
(The height measurement is completed)
+
Confirm the message
●To cancel
(The screen remains as it is in )
3
11
13-4-2
●Nozzle used
Head type Nozzle type
8 230C
3 1002
Calibration
Servo switch OFF
Servo switch ON
NPM-TT2 EJM1EE-MB-13M-02
12
Confirm that it has been
successfully completed
●If it has been successfully completed,
the display of each nozzle position is
changed from '-' to 'OK'.
(The head moves to the work position)
12
+
Placement head 2
13-4-3
Head / Plane calibration
Z 2
13
Prepare for plane calibration Z
14
Open the safety cover
15
16
Check the nozzle installation
positions
●Nozzle used
Head
type
Nozzle
position
Nozzle
type
8 No. 3 230C
3 No. 2 1002
Maintenance
13-4
Servo switch OFF
NPM-TT2 EJM1EE-MB-13M-02
21
Confirm that it has been
successfully completed, and
choose the other table for
plane calibration Z and then
repeat steps from to
21
19
2
20
13-4-4
17
18
Close the safety cover
+
Confirm the message
■To cancel
(The screen remains as it is
in )
13
19
Calibration
(The plane correction Z is calibrated)
Servo switch ON
20
Confirm the message
20
+
