NPM- TT2 EJ M1EE-MB-13M-0 2 25 26 27 28 29 Open the safety cover Remove nozzles Close the safety cover 24 + 13-4 -6 Prepare to remove nozzles 30 Confirm the message ■ To cancel (The screen remains as it is in . ) 22 30 C…
NPM-TT2 EJM1EE-MB-13M-02
Placement head 3
Head / Plane calibration
Z 3
13-4-5
22
Confirm that it has been
successfully completed
23
Confirm the message
(The plane calibration Z data is saved)
(The head moves to the work position)
■When you do not save the data
■To cancel
(The screen remains as it is in )
22
23
Maintenance
13-4
22
NPM-TT2 EJM1EE-MB-13M-02
25
26
27
28
29
Open the safety cover
Remove nozzles
Close the safety cover
24
+
13-4-6
Prepare to remove nozzles
30
Confirm the message
■To cancel
(The screen remains as it is in . )
22
30
Calibration
Servo switch OFF
Servo switch ON
NPM-TT2 EJM1EE-MB-13M-02
Width adjustment
1
4
3
2
+
Open the safety cover
Measure the conveyor width
with a vernier caliper
5
6
Close the safety cover
1
13-5-1
Explains the method for calibrating the width adjustment of the transfer conveyor.
Maintenance
13-5
Servo switch OFF
Servo switch ON
(The transfer conveyor width is adjusted
to the reference with)
Reference width
PC size conveyor: 317.5 mm
M size conveyor: 260.0 mm
Standard
PC size conveyor: 318.0 to 318.2 mm
M size conveyor: 260.5 to 260.7 mm
