NPM- TT2 EJ M1EE-MB-13M-0 2 W idth adjustment 1 4 3 2 + Open the safety cover Measure the conveyor width with a vernier caliper 5 6 Close the safety cover 1 13-5 -1 Explains the method for calibrating the width adjustmen…
NPM-TT2 EJM1EE-MB-13M-02
25
26
27
28
29
Open the safety cover
Remove nozzles
Close the safety cover
24
+
13-4-6
Prepare to remove nozzles
30
Confirm the message
■To cancel
(The screen remains as it is in . )
22
30
Calibration
Servo switch OFF
Servo switch ON
NPM-TT2 EJM1EE-MB-13M-02
Width adjustment
1
4
3
2
+
Open the safety cover
Measure the conveyor width
with a vernier caliper
5
6
Close the safety cover
1
13-5-1
Explains the method for calibrating the width adjustment of the transfer conveyor.
Maintenance
13-5
Servo switch OFF
Servo switch ON
(The transfer conveyor width is adjusted
to the reference with)
Reference width
PC size conveyor: 317.5 mm
M size conveyor: 260.0 mm
Standard
PC size conveyor: 318.0 to 318.2 mm
M size conveyor: 260.5 to 260.7 mm
NPM-TT2 EJM1EE-MB-13M-02
9
Repeat steps from to
until the above reference width
is achieved
8
10
(The offset value is set)
2
7
■When you do not save offset
(The screen remains as it is in )
9
Confirm the message
7
Adjust the transfer conveyor width
10
13-5-2
9
Calibration
●When pressing [Key rate], you can
change the response.
7
①Use [Key rate] to set the moving amount.
②Use to move the
conveyor.
+
●Adjust the value of “Offset” so that the
difference of the offset value and the
measured value in step
becomes 320.6mm.
(The value is displayed in “Offset”.)
4
●Adjust the value so that the measured
value in step becomes between
320.5 and 320.7 mm.
4
