NPM-TT2 EJM1EE-MB-13M-02
13-6-6
Calibration
NPM-TT2 EJM1EE-MB-13M-02
Height sensor (option) 1
Select a table
●Select a table to perform calibration.
(Work only at the front side)
1
The surface height of several points on the PCB top surface is measured by the height sensor, and
according to the result, PCB warpage condition is predicted and the nozzle lowering position is controlled
for placement operation. This operation procedure is also shared by the 8- and 3-nozzle heads.
●Remove all support pins before performing calibration.
●If the height sensor jig cannot be set up, manually load a PCB from the pre-process machine and set it
up using a workbench (please prepare yourself.)
2
+
3
Maintenance
13-7
12 3
●If there is PCB, remove it followed by
the instruction on the screen.
4
Confirm the message
■When you do not work
(The head remains as it is in )
1
4
(The width is adjusted)
(The head moves to the retraction
position)
Open the safety cover
6
5
7
Remove the PCB-support pin as
necessary
13-7-1
Servo switch OFF
(Confirm whether any PCB remains on
the transfer rail)
