NPM-TT2 EJM1EE-MB-13M-02
26
27
Confirm that it has been
successfully completed
Press the numerical part
(The numerical keypad appears)
13-8-1-6
Calibration
28
Enter the measured value
●Enter the value read in .
Input range: 15 to 25 N
25
28
29
●Reads a stable numerical value being
measured.
Load meas displays the standardized
value rather than the maximum value
since the numerical value goes up
momentarily when the nozzle and the
jig come in contact with each other so
that it becomes difficult to read the
measurement value accurately.
●How to change the load cell meter
display (→P.13-8-2)
+
(Calibration is carried out)
29
26
27
NPM-TT2 EJM1EE-MB-13M-02
Place-
ment
load
13-8-1-7
Placement load 4
31
Confirm that it has been
successfully completed
Press the numerical part
(The numerical keypad appears)
30
31
Maintenance
13-8-1
30
32
Enter the measured value
●Enter the value read in .
32
29
33
33
Confirm the message
●As for the other nozzle positions,
repeat steps from to .
12
33
NPM-TT2 EJM1EE-MB-13M-02
Choose the other table
●As for the other table, repeat steps
from to .
3
33
13-8-1-8
34
34
Calibration
35
36
35
36
Confirm the message
(It returns to the origin, and the data
obtained by calibration is lost)
(The data obtained by calibration is
saved)
■When you do not save the data
■To cancel
37
Prepare to remove nozzles
(The screen remains as it is
in )
34
(The head moves to the work position)
