NPM- TT2 EJM1EE-MB-13 M-02 Place- ment load 1 2 3 13-8-2 -3 Maintenance 13-8-2 Calibration method 1 ● You do not need to set the value because it is already initiali zed before shipment. ● Please calibrate the jig or the…

100%1 / 502
NPM-TT2 EJM1EE-MB-13M-02
13-8-2-2
MAX/MIN
Resets or changes
the display between
Current, MAX and
MIN values
LEVEL
Changes the
value
MODE
Changes display
parameters
SHIFT
Changes values set
to parameters and
shift the digit of the
set values
UP
Changes the set
values and
sets/cancels zero
forcing
Each letter of the alphabet used in describing the
set data or contents is as follows.
Names and functions of operation buttons
MAX/MIN
LEVEL
MODE
SHIFT
UP
Calibration
NPM-TT2 EJM1EE-MB-13M-02
Place-
ment
load
1
2
3
13-8-2-3
Maintenance
13-8-2
Calibration method 1
●You do not need to set the value because it is already initialized before shipment.
●Please calibrate the jig or the load cell after you replace it. Also, it is recommended that you calibrate it
every year.
Turn ON the power
Hold down
for at least three seconds
Confirm the input range
■If the screen display differs
Choose it with
4
5
Confirm the power-supply
frequency
6
(The input range is set)
(The power-supply frequency is set)
(The screen display flashes)
■If the screen display differs
(The screen display flashes)
Choose it with
3
5
34
6
2
How to use placement
load measurement jig
(option)2
NPM-TT2 EJM1EE-MB-13M-02
13-8-2-4
Confirm the display value
Put a 100 g weight on the load
cell
(The value is displayed, and the lamp
flashes)
(The input value 1 is set)
(Teaching is complete and then the lamp
changes from flashing to illumination)
Confirm that the display value
becomes stable
(The display value 1 is set)
■If the screen display differs
(The display flashes)
Choose it with
8
9810
9
11
1112
10
11
7
8
9
12
Calibration
