NPM- TT2 EJ M1EE-MB-13M-0 2 Place- ment load Maintenance 13-8-2 Put a 1 kg weight on the load cell (The value is displayed, and the lamp flashes) (Teaching is complete and then the lamp changes from flashing to illuminat…
NPM-TT2 EJM1EE-MB-13M-02
13-8-2-4
Confirm the display value
Put a 100 g weight on the load
cell
(The value is displayed, and the lamp
flashes)
(The input value 1 is set)
(Teaching is complete and then the lamp
changes from flashing to illumination)
Confirm that the display value
becomes stable
(The display value 1 is set)
■If the screen display differs
(The display flashes)
Choose it with
8
9810
9
11
1112
10
11
7
8
9
12
Calibration
NPM-TT2 EJM1EE-MB-13M-02
Place-
ment
load
Maintenance
13-8-2
Put a 1 kg weight on the load
cell
(The value is displayed, and the lamp
flashes)
(Teaching is complete and then the lamp
changes from flashing to illumination)
Confirm that the display value
becomes stable
(The input value 2 is set)
Confirm the display value
(The display value 2 is set)
■If the screen display differs
(The display flashes)
Choose it with
14
151410
15
17
1718
13
14
15
16
17
18
Calibration method 2
13-8-2-5
How to use placement
load measurement jig
(option)3
NPM-TT2 EJM1EE-MB-13M-02
13-8-2-6
19
19
20
21
1920
21
Confirm the decimal point position
(The decimal point position is set)
■To change
(The screen display flashes)
Hold down
for at least a second
(Returns to the operation level)
Choose it with
Calibration
