NPM-TT2 EJM1EE-MB-13M-02
13-9-1
Maintenance
13-9
Multi-recognition
camera 1
Taking an example of 8-nozzle head, it describes the operation method of multi-recognition camera.
Remove the feeder, if any, from the table you are going to calibrate beforehand.
Choose a head
+
●Choose the head you want to calibrate.
12
2
1
(The head moves to the work position)
Open the safety cover
Install the multi-recognition
camera jig
●Nozzles used
Head
type
Nozzle
position
8 No. 3
3 No. 2
Servo switch OFF
3
4
5
Close the safety cover
Servo switch ON
6
7
Multi-recognition camera jig
For 8-nozzle head For 3-nozzle head
NPM-TT2 EJM1EE-MB-13M-02
13-9-2
Calibration
+
Confirm the message
■To cancel
(The screen remains as it is in )
8
1
+
9
(The head moves to the work position)
9
Confirm that it has been
successfully completed
8
Prepare to attach the jig
Servo switch OFF
Open the safety cover
Head
type
Nozzle position
Before replace After replace
8 No. 3 No. 6
3 No. 2 No. 1
10
11
12
13
Replace the multi-recognition
camera jig
●Nozzles that you confirm
