NPM-TT2 EJM1EE-MB-13M-02
13-10-10
Calibration
NPM-TT2 EJM1EE-MB-13M-02
Split recognition 1
13-11-1
Maintenance
13-11
This is used when the component to be recognized is larger than the standard one. The image is split and
recognized, and the correction value is calculated and PCB is mounted. (for 3-nozzle head only)
●QFP, connector X-direction: to 145.2 mm, Y-direction: 45 to 80 mm
●Components other than the above, X-direction: to 145.2 mm, Y-direction: 45 to 90 mm
1
2
Select a table
3
Select a nozzle
Select a nozzle to measure.
4
Confirm that the servo switch
is ON
(If OFF, change to ON)
5
+
(Select 3-nozzle head only)
1
2
3
4
5
NPM-TT2 EJM1EE-MB-13M-02
13-11-2
Calibration
Open the safety cover
9
8
13
10
11
Place the multi-recognition
camera jig to the
predetermined head
Confirm the message
■When you do not retract
(The screen remains as it is in )
1
6
(The head moves to the retraction
position of the feeder cart side
6
+
12
Close the safety cover
13
multi-recognition
camera jig
(for 3-nozzle
head)
Confirm the message and
prepare for installing the multi-
recognition camera jig
■When you do not install the multi-
recognition camera jig
(The screen remains as it is in )
1
7
(The head performs recognition operation)
+
Confirm the message
Servo switch OFF
Servo switch ON
