NPM- TT2 EJ M1EE-MB-13M-0 2 Explains the operation procedure, taking for an example, the 8- no zzle head; however, the same procedure can also be applied to the 3-nozzle heads. Remove the feeders from the slots indicated…

100%1 / 502
NPM-TT2 EJM1EE-MB-13M-02
13-11-4
Calibration
22
21
19
23
Remove the multi-recognition
camera jig
The selected menu (other
menu) is displayed
20
20
Confirm the message
■When you do not remove the multi-
recognition camera jig
(The screen remains as it is in )
14
Close the safety cover
Servo switch ON
NPM-TT2 EJM1EE-MB-13M-02
Explains the operation procedure, taking for an example, the 8-nozzle head; however, the same
procedure can also be applied to the 3-nozzle heads.
Remove the feeders from the slots indicated in the following conditions beforehand;
●For 13-slot feeder: No. 18, 19, 20, 23, 24, 25, 28, 29, 30
●For feeder cart : No.1, 2, 3, 8, 9,10,15,16,17
13-12-1
Maintenance
13-12
Pickup position 1
2
Choose a table
●Choose the table for calibration.
+
2
3
1
3
1
(The head moves to the working
position.)
NPM-TT2 EJM1EE-MB-13M-02
Open the safety cover
6
5
4
Prepare to install the nozzle
7
9
8
Close the safety cover
13-12-2
Install nozzles
●Nozzle used
Head
type
Nozzle
position
Nozzle
type
8 No. 3 230C
3 No. 2 1002
10
■To cancel
(The screen remains as it is
in )
3
Confirm the message
10
+
Calibration
(The head moves to the working
position.)
Servo switch OFF
Servo switch ON
