NPM-TT2 EJM1EE-MB-13M-02
Open the safety cover
6
5
4
Prepare to install the nozzle
7
9
8
Close the safety cover
13-12-2
Install nozzles
●Nozzle used
Head
type
Nozzle
position
Nozzle
type
8 No. 3 230C
3 No. 2 1002
10
■To cancel
(The screen remains as it is
in )
3
Confirm the message
10
+
Calibration
(The head moves to the working
position.)
Servo switch OFF
Servo switch ON
NPM-TT2 EJM1EE-MB-13M-02
13-12-3
No. 19 slot
13
(Calibration is carried out)
■To cancel
(The screen remains as it is
in )
3
Confirm the message
13
+
■For a 13-slot feeder
Maintenance
13-12
Set the jig to the 19th slot on the table selected
in step .
1
Set the jig to the second slot on the table
selected in step .
1
No. 2 slot
■For a feeder cart
11
Pickup position height
teaching jig
11
Install the pickup position
height teaching jig
12
+
Pickup position 2
NPM-TT2 EJM1EE-MB-13M-02
14
Install the pickup position
height teaching jig
13-12-4
15
■For a 13-slot feeder
No. 24 slot
(Calibration is carried out)
■To cancel
(The screen remains as it is
in )
3
Confirm the message
+
15
Set the jig to the 24th slot on the table selected
in step .
1
No. 9 slot
Set the jig to the 9th slot on the table selected
in step .
1
■For a feeder cart
Calibration
