NPM-TT2 EJM1EE-MB-13M-02
13-12-3
No. 19 slot
13
(Calibration is carried out)
■To cancel
(The screen remains as it is
in )
3
Confirm the message
13
+
■For a 13-slot feeder
Maintenance
13-12
Set the jig to the 19th slot on the table selected
in step .
1
Set the jig to the second slot on the table
selected in step .
1
No. 2 slot
■For a feeder cart
11
Pickup position height
teaching jig
11
Install the pickup position
height teaching jig
12
+
Pickup position 2
NPM-TT2 EJM1EE-MB-13M-02
14
Install the pickup position
height teaching jig
13-12-4
15
■For a 13-slot feeder
No. 24 slot
(Calibration is carried out)
■To cancel
(The screen remains as it is
in )
3
Confirm the message
+
15
Set the jig to the 24th slot on the table selected
in step .
1
No. 9 slot
Set the jig to the 9th slot on the table selected
in step .
1
■For a feeder cart
Calibration
NPM-TT2 EJM1EE-MB-13M-02
16
Install the pickup position
height teaching jig
13-12-5
17
■To cancel
(The screen remains as it is
in )
3
Confirm the message
17
No. 29 slot
+
Maintenance
13-12
Set the jig to the 29th slot on the table
selected in step .
1
■For a 13-slot feeder
■ For a feeder cart
No. 16 slot
Set the jig to the 16th slot on the table
selected in step .
1
Pickup position 3
