NPM-TT2 EJM1EE-MB-13M-02
13-12-8
Calibration
NPM-TT2 EJM1EE-MB-13M-02
Tray 1
13-13-1
+
prepare to install nozzles
Open the safety cover
Explains the tray calibration procedure.
●This task cannot be performed when the tray feeder is not installed.
●It is applicable for 8- and 3-nozzle heads.
Maintenance
13-13
1
1
2
3
4
Servo switch OFF
NPM-TT2 EJM1EE-MB-13M-02
Close the safety cover
Install nozzles for the nozzle
changer
+
■To cancel
(The screen remains as it is
in )
Confirm the message
(The nozzle pickup height is measured)
13-13-2
●Nozzle used
Head
type
Changer
position
Nozzle
type
8
No. 11
230C
3 1002
+
(Pickup position 1 is calibrated)
Confirm that it has been
successfully completed
7
6
5
8
1
8
9
9
Calibration
Servo switch ON
