NPM- TT2 EJ M1EE-MB-14M-0 2 14-9 -7 Maintenance 14-9 Ho w to s witch the 17-slot f eeder car t and the single tr ay f eeder 4 ① Switching the single tray feed er to the 17-slot feeder cart 3 22 Insert the metal fitting o…
NPM-TT2 EJM1EE-MB-14M-02
14-9-6
To
19
18
B
Push the end of the drive unit
against the pin A, turn it
clockwise so that its groove
hits the pin B. Then tighten
the screws.
A
●Screw: M10 2 locations
15
Loosen the
screws of the
sensor bracket
14
Loosen the knob,
move it from
“CHANGE” to
“CART” and fix
Knob
Installation
13
Loosen the screws all the way
Install the cart drive unit
Loosen the screws, pull the knob toward you,
move the sensor bracket downward and
temporarily fix the screws
Sensor bracket
Sensor switch
●Screw:
M4 2 locations
●Screw: M4 2 locations
Sensor bracket
knob
NPM-TT2 EJM1EE-MB-14M-02
14-9-7
Maintenance
14-9
How to switch the 17-slot
feeder cart and the single
tray feeder 4
①Switching the single tray feeder to the 17-slot feeder cart 3
22
Insert the metal fitting of the safety cover to
the safety switch
23
Attach the
feeder table
cover
●Screw: M4
2 locations
19
Remove the short connector and install the cables and pipes of the cart
drive unit
Short connector
Store the removed short connector to the switch cart (→P.14-9-1)
24
25
ON
Unlock the
machine and
Metal fitting
Attach the feeder
cart
(→P.3-2)
26
Cable, pipe
NPM-TT2 EJM1EE-MB-14M-02
14-9-8
20
Attach the extension drawer
●Screw: M6 2 locations
Insert the pins of the connector to
the holes of the extension drawer
to position
Pin
Remove the screws
21
Insert the safety cover from the top to install
●Screw: M6 2 locations
Store the removed screws
to the switch cart
(→P.14-9-1)
Tighten the screws
●Screw: M6
2 locations
Safety cover
Installation
Pin
Align the position of pins and
seals and tighten the screws
Seal
