15 Others
NPM-TT2 EJM1EE-MB-14M-02
14-9-15
Checking the air pressure
A
A
How to switch the 17-slot
feeder cart and the single
tray feeder 8
Maintenance
14-9
1
2
Check the air
pressure
●Air pressure:
0.30 to 0.35 MPa
If it is outside the
specified range,
adjust the air
pressure by
turning the
regulator knob
1
2
3
Regulator
■Single tray feeder
Air pressure gauge
Calibration
STEP Item Action Reference
STEP4 Tray
Pickup height
(→P.13-1-2、13-13)
Pickup position 1
Pickup position 2
If the tray feeder is removed or installed, calibration must be performed.
Unlock.(pull it forward)
Adjust the pressure.(rotate)
Lock.(push it rearward)
15 Others
NPM-TT2 EJM1EE-MB-15M-00
15-1-1
The status and history of Plug and Play on the machine can be checked.
(The status of Plug and Play on the
machine is displayed)
A
(The history of Plug and Play on the
machine is displayed)
B
Maintenance
15-1
Machine information
