NPM- TT2 EJM1EE-MB-16 M-00 Feeder cart drive unit No. Component nam e Weight ( g ) Q’ty Material c omponent contents and amount (filler, reinforcement) Insert material Feeder cart drive unit guide 150 2 POM (polyacetal) …
NPM-TT2 EJM1EE-MB-16M-00
16-1-2
No. Component name
Weight (g)
Q’ty
Material component contents
and amount
(filler, reinforcement)
Insert material
Cable bearer
(X-axis)
420 2
PA
(polyamide)
Cable bearer
(Y-axis)
700 2
PA
(polyamide)
A
B
XYユニット
XY unit
A
A B
Reference
NPM-TT2 EJM1EE-MB-16M-00
Feeder cart drive unit
No. Component name
Weight (g)
Q’ty
Material component contents
and amount
(filler, reinforcement)
Insert material
Feeder cart drive unit guide 150 2
POM
(polyacetal)
Plastic parts listing 2
Maintenance
16-1
16-1-3
A
A
NPM-TT2 EJM1EE-MB-16M-00
No. Component name
Weight (g)
Q’ty
Material component contents
and amount
(filler, reinforcement)
Insert material
13-slot supply unit guide 230 2
POM
(polyacetal)
13-slot supply unit used-tape
box
550 2
PP
(polypropylene)
A
B
16-1-4
13-slot supply unit
A
B
Reference
