N7201A653E - 第479页
NPM- TT2 EJM1EE-MB-16 M-00 No. Component nam e Weight ( g ) Q’ty Material c omponent contents and amount (filler, reinforcement) Insert material 13-slot supply unit guide 230 2 POM (polyacetal) 13-sl ot supply un it used…
NPM-TT2 EJM1EE-MB-16M-00
Feeder cart drive unit
No. Component name
Weight (g)
Q’ty
Material component contents
and amount
(filler, reinforcement)
Insert material
Feeder cart drive unit guide 150 2
POM
(polyacetal)
Plastic parts listing 2
Maintenance
16-1
16-1-3
A
A
NPM-TT2 EJM1EE-MB-16M-00
No. Component name
Weight (g)
Q’ty
Material component contents
and amount
(filler, reinforcement)
Insert material
13-slot supply unit guide 230 2
POM
(polyacetal)
13-slot supply unit used-tape
box
550 2
PP
(polypropylene)
A
B
16-1-4
13-slot supply unit
A
B
Reference
NPM-TT2 EJM1EE-MB-16M-00
16-1-5
No. Component name
Weight (g)
Q’ty
Material component contents
and amount
(filler, reinforcement)
Insert material
Replenish-section door 424 1
PC
(polycarbonate)
Inside plate of Replenish-
section
112 1
PC
(polycarbonate)
Magazine door window 207 1
PC
(polycarbonate)
Refuse box 300 1
PP
(polypropylene)
A
B
XYユニット
Tray feeder
C
Plastic parts listing 3
Maintenance
16-1
D
A
D
C
B
