17 Appendix
NPM-TT2 EJM1EE-MB-16M-00
Plastic parts listing 4
No. Component name
Weight (g)
Q’ty
Material component contents
and amount
(filler, reinforcement)
Insert material
Window on the extension
conveyor
600 1
PC
(polycarbonate)
Maintenance
16-1
A
16-1-7
Extension conveyor
A
17 Appendix
NPM-TT2 EJM1EE-MB-17M-00
17-1
Maintenance
17-1
Switch process
Time required：Single tray feeder ⇔ 17-slot feeder cart 30 minutes each
Tool used：Spanner 30 mm (2)
Allen wrench (3 mm, 4 mm, 5 mm, 8 mm)
Wrench width
Spanner width
This chapter describes the summarized version of the procedure to switch between the cart and tray feeder.
Separate this chapter and use at the working site as necessary.
For details, see the followings.
(→ P.14-9)
