NPM-TT2 EJM1EE-MB-17M-00
Maintenance
17-3-1
Name
and
layout
Parts layout installed
to the feeder cart
Describes the procedure of the common items for switching between the 17-slot feeder cart and tray feeder.
(b) Drive guide
(a) Cart drive unit
(e) Extension drawer
(c) Cart guide
Switch parts are stored in the cart
(d) Safety cover
17-3-1
Grommet
(2 pieces)
Short
connector
Screw:M6
(2 pieces)
(f) Part box and stored parts in the box
NPM-TT2 EJM1EE-MB-17M-00
Maintenance
17-3-2
Name
and
layout
Parts layout when the
single tray feeder is used
Describes the procedure of the common items for switching between the 17-slot feeder cart and tray feeder.
(f) Short connector
(f) Screw:M6 (2 pieces)
17-3-2
NPM-TT2 EJM1EE-MB-17M-00
Name
and
layout
Parts layout when the 17-
slot feeder cart is used
(a) Cart drive unit
(f)Grommet
Maintenance
17-3-3
17-3-3
(e) Extension
drawer
(d) Safety cover
(b) Drive guide
(c) Cart guide
Describes the procedure of the common items for switching between the 17-slot feeder cart and tray feeder.
