NPM-TT2 EJM1EE-MB-02M-01
2-1-2-4
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1
Components-
ejection conveyor
Components detection sensor OFF
Cleaning 2 6-12
Conveyor belt OFF
2 Extension conveyor
PCB transfer belt OFF Check 10 6-5
PCB detection sensor OFF Cleaning 3 6-9
3 Tray feeder lifter
Ball screw OFF
Apply grease
(LCG100)
20 6-13
Linear guide OFF
4 Tray feeder drawer
Linear guide OFF
Grease
dispensing
(LCG100)
Cam plate (inside) OFF
Cam block OFF
5
Tray feeder
magazine
(per magazine)
Slot OFF Cleaning 10 6-14
6
Support pin
automatic change
Nozzle /nozzle changer for
support pins
OFF Cleaning 10 6-18
7 Height sensor
Light-emitting and light-receiving
glasses
OFF Cleaning 5 6-19
■ Others (option)
■ 3-nozzle head (option)
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1
Nozzle
(per three)
Nozzle reflector
OFF Cleaning 15 6-4
Nozzle tip
Nozzle flange upper surface
(2D code area)
2 Nozzle changer Nozzle reflector contact surface
3 Placement head Large reflector OFF Cleaning 15 6-6
Inspection time (min)
= 2 x (the number of components-ejection conveyors) + 13 x (the number of extension
conveyors) + 20 x (the number of tray feeders) + 10 x (the number of tray feeder
magazines) + 10 (when support pin automatic change function is enabled) + 5 x (the
number of Height sensors)
Inspection time (min) = 30 x (the number of heads)
Overview
NPM-TT2 EJM1EE-MB-02M-01
Every-3000-hours (every 6 months) inspection items
2-1-2-5
■ Types in common
Overview
Periodic inspection
items by cycle 3
Maintenance
2-1-2
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1 Main controller Filter OFF Cleaning 20 8-1
Inspection time (min) = 20
■LNB (option)
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1 FA computer Filter OFF Cleaning 5 8-2
Inspection time (min) = 5
■ 8-nozzle head (option)
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min
]
Ref.
1
Nozzle holder
(per head)
Spring for nozzle cushion
OFF Cleaning 30
7-1
Inner and outer circumferences
Spring for holding clamp claws
Clamp claw
Filter
Taper surface
Nozzle-holder shaft
Nozzle holder slicing surface OFF
Cleaning
84
Grease dispensing
(FL100)
Inspection time (min) = 114 x (the number of heads)
Every-1000-hours (every two months) inspection items
NPM-TT2 EJM1EE-MB-02M-01
2-1-2-6
Every-18000-hours (every 3 years) inspection items
■ Types in common
■ 8-nozzle head (Option)
■ 3-nozzle head (Option)
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1 XY unit Cable bearer OFF Check 5 10-2
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1
Nozzle holder
(per head)
Clamp claw
OFF Check 10 10-1Spring for holding clamp claws
Spring for nozzle cushion
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1
Nozzle holder
(per head)
Clamp claw
OFF Check 10 10-1
Spring for holding clamp claws
Inspection time (min) = 5
Inspection time (min) = 10 x (the number of heads)
Inspection time (min) = 10 x (the number of heads)
Overview
Every-6000-hours (yearly) inspection items
■ 3-nozzle head (Option)
■ Types in common
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1 Touchscreen
Backlight
ON
Check 2 9-1
Hinge (Front and rear sides)
Grease dispensing
(TOUCH LUBE)
59-2
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1 Nozzle 1006 nozzle OFF Check 1 9-3
Inspection time (min) = 7
Inspection time (min) = 1 x (the number of nozzles)
