NPM- TT2 EJM1EE-MB-02 M-01 2-1-3 -2 ■ 8-nozzle head (option) No. Unit name Check and grea sing location Check and grease points Cycle [h] Ref. 24 140 560 1000 3000 6000 18000 1 Placement head Vacuum air path Check ○ 6-10…

100%1 / 502
NPM-TT2 EJM1EE-MB-02M-01
Overview
Periodic inspection
items by unit 1
No. Unit name
Check and greasing
location
Check and
grease
points
Cycle [h]
Ref.
24 140 560 1000 3000 6000 18000
1
Main body
unit
Main air pressure
(Pressure gauge)
Air
pressure
check
○
4-1-1
Vacuum pump supply
pressure
(Pressure gauge)
○
Vacuum break pressure
(Pressure gauge)
○
Clean blow pressure
(Pressure gauge)
○
Components-ejection box
Cleaning
○
4-2-1
Vacuum pump filter
○
6-7
Emergency stop switch
Check
○
6-8
Tray connection safety
switch
○
6-8
Air drain (Regulator)
○
6-16
2 XY unit
X-,Y- axis linear guide
Apply
grease
○
6-2
X-,Y- axis Cable bearer Cleaning
○
6-20
X-,Y- axis Cable bearer Check
○
10-2
3
PCB
conveyor
PCB-support blocks Cleaning
○
5-3
Linear guide
Grease
dispensing
○
6-1
Ball spline
○
6-1
Width-adjustment ball
screw
Apply
grease
○
6-1
PCB transfer belt Check
○
6-5
PCB detection sensor Cleaning
○
6-9
4 Cover
Safety switch Check
○
6-8
Safety cover Cleaning
○
6-15
5
Touchscree
n
Color touchscreen face Cleaning
○
5-1
Backlight Check
○
9-1
Hinge
Grease
dispensing
○
9-2
6
Multi-
recognition
camera
Cover glass Cleaning
○
5-4
7
Main
controller
Filter Cleaning
○
8-1
8
13-slot
feeder
Inside of the
used-tape box
Cleaning
○
4-2-2
Feeder table
○
5-5
Cutting unit
Apply
grease
○
6-17
Connector Check
○
5-7
2-1-3-1
Maintenance
2-1-3
The lists below show check and grease locations, information, and cycles organized by unit.
■ Types in common
NPM-TT2 EJM1EE-MB-02M-01
2-1-3-2
■ 8-nozzle head (option)
No. Unit name
Check and greasing
location
Check and
grease
points
Cycle [h]
Ref.
24 140 560 1000 3000 6000 18000
1
Placement
head
Vacuum air path
Check
○
6-10
Θ-axis belt
○
6-11
2 Nozzle holder
Spring for nozzle
cushion
Cleaning
○
7-1
Spring for nozzle
cushion
Check
○
10-1
Spring for holding clamp
claws
Cleaning
○
7-1
Spring for holding clamp
claws
Grease
dispensing
○
6-3
Spring for holding clamp
claws
Check
○
10-1
Clamp claw Cleaning
○
7-1
Clamp claw
Grease
dispensing
○
6-3
Clamp claw Check
○
10-1
Inner and outer
circumferences
Cleaning
○
7-1
Filter Cleaning
○
Taper surface Cleaning
○
Nozzle holder shaft Cleaning
○
Nozzle holder slicing
surface
Cleaning
○
Grease
dispensing
○
3 Nozzle
Nozzle taper surface Cleaning
○
6-4
Nozzle reflector Cleaning
○
Nozzle tip Cleaning
○
Nozzle inside Cleaning
○
Nozzle flange upper
surface
(2D code area)
Cleaning
○
4
Nozzle
changer
Nozzle reflector contact
surface
Cleaning
○
Overview
NPM-TT2 EJM1EE-MB-02M-01
2-1-3-3
■ 3-nozzle head (option)
No. Unit name
Check and
greasing location
Check and
grease
points
Cycle [h]
Ref.
24 140 560 1000 3000
600
0
1800
0
1 Placement head Large reflector Cleaning
○
6-6
2 Nozzle holder
Filter
Cleaning
○
5-2
Taper surface
○
Clamp claw
Grease
dispensing
○
Clamp claw Check
○
10-1
Spring for holding
clamp claws
Check
○
3 Nozzle
Nozzle reflector
Cleaning
○
6-4
Nozzle tip
○
1006 nozzle Check
○
9-3
Nozzle flange
surface
(2D code area)
Cleaning
○
6-4
4 Nozzle changer
Nozzle reflector
contact surface
○
Overview
Periodic inspection
items by unit 2
Maintenance
2-1-3
