NPM- TT2 EJM1EE-MB-02 M-01 2-1-6 -10 Components-ejection conveyor Overview Maintenance 2-1-6 Component detection sensor Conveyor belt P eriodic inspection points by unit 6 <Other s> (Option) Overview
NPM-TT2 EJM1EE-MB-02M-01
Periodic inspection points by
unit 5 < placement head >
(Option)
2-1-6-9
Overview
Maintenance
2-1-6
3-nozzle head
■3-nozzle head ■Nozzle
■Nozzle holder
■Nozzle changer
Clamp claw
Spring for holding clamp
claws
Taper surface
Nozzle reflector
contact surface
Vacuum air path
Θ-axis belt
Nozzle reflector
Nozzle flange
upper surface
(2D code area)
Nozzle tip
NPM-TT2 EJM1EE-MB-02M-01
2-1-6-10
Components-ejection conveyor
Overview
Maintenance
2-1-6
Component
detection sensor
Conveyor belt
Periodic inspection points
by unit 6 <Others>
(Option)
Overview
NPM-TT2 EJM1EE-MB-02M-01
2-1-6-11
Single tray feeder main unit
Overview
Maintenance
2-1-6
Periodic inspection points
by unit 7 <Others>
(Option)
Refuse box
Single tray feeder lifter
Ball screw
Linear guide
Tray feeder drawer
