{TzYG|˅Gn {TzYG|˅Gn 2-60 2.4.4.7 . Table 分解图及零件表

2-59

附加装置

No. Part No. Part Name Q'ty

Service

Material

Remarks

1 FC15-005419A COVER-PART PANEL COVER_SM1-FWS-025 1

2 FC30-005154A PLATE-PART PANEL_SM1-FWS-204;FLMS 1

3 EP05-001033A CONCENT-FLMS_SM1-FWS-062;FLMS,2 1 AC220V2P

4 EP06-002798A UPS/SMPS-SMPS1_RSP500-24 4

5 FC09-008078A BRACKET-SMPS BRK1_SM1-FWS-203;FLMS 4

6 FC07-003939A BLOCK-GND BLOCK_SM1-FWS-206;FLMS 1

7 EP03-001057A DUCT,CABLE-CABLE DUCT_30X40;FLMS 5

8 EP21-001032A BLOCK,TERMINAL-TERMINAL

BLOCK_KH6010;FLM

9 FC09-008079A BRACKET-PANEL1_BRK_SM1-FWS-205;FLMS 1

10 FC30-005155A PLATE-PANEL1_SM1-FWS-207 1

11 EP20-001032A SWITCH,ETC-S-S/W1_8216;FLMS 4

{TzYG|˅Gn{TzYG|˅Gn

2-60

2.4.4.7.

Table 分解图及零件表

2-61

附加装置

No. Part No. Part Name Q'ty

Service

Material

Remarks

1 TO05-001118A TABLE-FLMS_SM1-FWS-029;FLMS 1

2 FC09-008113A BRACKET-TABLE_BK_SM1-FWS-030 1

3 FC29-007420A HANDLE-MOVE WHEEL_SM1-FWS-031 1

4 FC29-008800A STAND-MONITOR STAND_SM1-FWS-

208;FLMS,STA

5 FC09-008077A BRACKET-SCANNER_BRK_SM1-FWS-

209;FLMS

6 CD06-001004A MONITOR-MONITOR_P2217H;FLMS 1 DELL

7 MC14-001058A HUB-USB HUB_PUH-945_FLMS 1 COSY

8 CD04-001007A KEYBOARD-5510M_FLMS 1

9 CD04-001008A COMPUTER MOUSE-OPTICAL MOUSE

V2.0_FLMS

10 CD04-001009A SCANNER,BARCODE-LS2208AP(USB) 1
