CM212-M - 第48页
4-D 全 体 カバー W hole Cover パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N610023571AB ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - M35 ( KN610023571AB-16-4 )
Ref
No.
Remarks
R
1
Q'ty
4-C
全
体
カバー
Whole Cover
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610023571AB
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
COVER
1
6 N210034906AC
COVER
1
7 N210034911AB
COVER
1
9 N210027752AB
COVER
1
10 N210045777AC
COVER
1
12 N210023302AA
COVER
1
18 N210006136AA
COVER
1
24 N210034912AB
COVER
1
26 N210034913AD
COVER
2
27 N210027796AD
COVER
1
31 N210045780AE
COVER
1
33 N210045793AE
COVER
1
34 N210027684AA
BRACKET
2
41 N210035127AA
BRACKET
1
44 N210038969AA
BRACKET
2
45 N210027716AA
SWITCH
2
49 N510015338AA
S
D4NS-1BF
JOINT
2
50 KXF06F4AA00 53015030-WM
CAP
12
51 KXF0ATKAA00 SFA-905
NUT
12
52 N510016442AA HTDSN5-5
SPACER
2
60 KXF01AAAA00 BSU-415
WASHER
2
61 KXF0DYNPA00 WSSB6-4-2
SPACER
2
62 KXF06PVAA00 BSU-425
TRIM
1
65 KXF0E32EA00 4100-B-3X16C
SCREW
4
76 N510018279AA
Cross recessed Truss head machine screw M4X6-4.8 A2J (Trivalent)
SCREW
62
81 N510018302AA
Cross recessed Truss head machine screw M5X8-4.8 A2J (Trivalent)
SCREW
8
82 N510018282AA
Cross recessed Truss head machine screw M4X8-4.8 A2J (Trivalent)
WASHER
5
83 N510018762AA
Toothed lock washer 4 External toothed Steel Unichrome white (Trivalent)
BUSH
1
86 KXF0DUDAA00 CE-012
WASHER
8
87 N510013724AA TM-147-2V
WASHER
60
88 N510013725AA TM-147-3V
FRAME
2
90 N510012210AA SFF-204 L=1470
BOLT
4
95 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
5
96 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
8
99 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
4
102 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
WASHER
21
103 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
36
109 N510020100AA Thick washer for M5
NUT
4
115 N510022614AA Domed cap nut Type-3 M4-4T A2J (Trivalent)
BOLT
4
117 N510017361AA
Hexagon socket head cap screw M4X30-10.9 A2J (Trivalent)
COVER
2
123 N210049593AB
BRACKET
2
124 N210052551AA
COVER
1
125 N210047425AA
BOLT
4
130 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
NUT
2
131 N510017862AA
Hexagon nut Type-1 Best class M5-6H-4T A2J (Trivalent)
WASHER
5
136 N510018765AA
Toothed lock washer 5 External toothed Steel Unichrome white (Trivalent)
M34
--
( KN610023571AB-16-3 )
4-D
全
体
カバー
Whole Cover
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610023571AB
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M35
( KN610023571AB-16-4 )
Ref
No.
Remarks
R
1
Q'ty
4-D
全
体
カバー
Whole Cover
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610023571AB
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
COVER
1
18 N210006136AA
BRACKET
2
19 N210043233AC
COVER
2
20 N210027682AA
COVER
2
21 N210023272AA
COVER
2
22 KXFB03UKA00
COVER
1
25 N210027754AD
COVER
1
43 N210027753AA
SWITCH
2
49 N510015338AA
S
D4NS-1BF
JOINT
2
50 KXF06F4AA00 53015030-WM
SPACER
2
60 KXF01AAAA00 BSU-415
WASHER
2
61 KXF0DYNPA00 WSSB6-4-2
SPACER
2
62 KXF06PVAA00 BSU-425
PACKING
4
63 KXF0DKJAA00
S
UC-300286(DA 0DKJA)
PACKING
4
64 KXF0DKKAA00
S
UC-300286(DA 0DKKA)
TRIM
1
65 KXF0E32EA00 4100-B-3X16C
SCREW
10
76 N510018279AA
Cross recessed Truss head machine screw M4X6-4.8 A2J (Trivalent)
SCREW
6
81 N510018302AA
Cross recessed Truss head machine screw M5X8-4.8 A2J (Trivalent)
WASHER
11
83 N510018762AA
Toothed lock washer 4 External toothed Steel Unichrome white (Trivalent)
BUSH
1
85 KXF0DUDAA00 CE-012
WASHER
4
88 N510013725AA TM-147-3V
MEIBAN
1
93 KXF0DXPLA00 P-18(screw)
BOLT
5
95 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
12
96 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
8
99 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
4
101 N510017470AA
Hexagon socket head cap screw M8X16-10.9 A2J (Trivalent)
WASHER
13
103 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
12
104 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
6
108 N510020099AA Thick washer for M4
WASHER
4
109 N510020100AA Thick washer for M5
WASHER
4
110 N510020102AA Thick washer for M8
NUT
2
112 N510017855AA
Hexagon nut Type-1 Best class M4-6H-4T A2J (Trivalent)
NUT
4
115 N510022614AA Domed cap nut Type-3 M4-4T A2J (Trivalent)
BOLT
4
117 N510017361AA
Hexagon socket head cap screw M4X30-10.9 A2J (Trivalent)
BOLT
4
130 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
NUT
2
131 N510017862AA
Hexagon nut Type-1 Best class M5-6H-4T A2J (Trivalent)
BAR
4
132 N210049616AA
STOPPER
2
133 N210049617AB
BRACKET
2
134 N210049615AC
SPACER
4
135 N510020966AA CB-512E
WASHER
10
136 N510018765AA
Toothed lock washer 5 External toothed Steel Unichrome white (Trivalent)
BOLT
4
137 N510017399AA
Hexagon socket head cap screw M5X25-10.9 A2J (Trivalent)
WASHER
8
145 N510018332AA Spring lock washer No.2 5 S A2J (Trivalent)
M36
--
( KN610023571AB-16-4 )
