17 PCB Warpage PCB warpage across the dire ction of travel max. 1 % of the PCB diagonal, but not exceeding 2 mm PCB warpage on the conveyor Fixed clamped edge Movable clamping device PCB Fixed clamped edge Conveyor belt …
16
Board Conveyor
Technical Data
Single conveyor
Standard dimensions (length x width)
With buffering
Without buffering
a
a) On request
50 mm x 50 mm to 460 mm x 460 mm
50 mm x 50 mm to 490 mm x 460 mm
With “Long Board”option 1030 (length x width)
Single step mode
Two step mode
a
50 mm x 50 mm to 610 mm x 460 mm
50 mm x 50 mm to 1030 mm x 460 mm
With “Long Board”option 1200 (length x width) 70 mm x 50 mm to 1200 mm x 460 mm
Stationary conveyor side Right, Left
Automatic electrical width adjustment Standard
PCB thickness
Standard 0.3 mm to 4.5 mm
PCB warpage See page 17
PCB weight
b
Standard
b) The board weight value refers to the weight of the board plus the weight of the components.
max. 2.0 kg
Clearance on PCB underside
c
c) The free positioning of support pins is limited by the stop bar.
25 mm
PCB conveyor height
Standard:
Option:
900 mm to 930 mm
950 mm
Type of interface:
Standard: SMEMA
Component-free PCB handling edge 3.0 mm
PCB changeover time
Single conveyor < 1.5 seconds
17
PCB Warpage
PCB warpage across the direction of travel
max. 1 % of the PCB diagonal, but not
exceeding 2 mm
PCB warpage on the conveyor
Fixed clamped edge
Movable clamping device
PCB
Fixed clamped edge
Conveyor belt
PCB transport direction
Front board edge
Front board edge
PCB warpage in direction of travel + PCB thickness < 5.5 mm
Bending up of front board edge max. 2.5 mm
Left conveyor belt
Right conveyor belt
PCB transport direction
18
PCB Warpage
PCB warpage during placement
PCB warpage downwards max. 0.5 mm
Use the magnetic pin supports, to achieve
this value.
When there is warpage under 2 mm, the
inkspots in the center of the board are also
within the focus of the digital camera. When
all the tolerances are taken into account,
this value is reduced to 1.5 mm.
You should also note that the warpage
reduces the component height.
Magnetic pin support
